Hot sale diesel small concrete dumper with rubber crawler
- Category: Dump Trucks >>>
- Supplier: Jining Haohong Industrial And Mining Equipment Co. Ltd.
Share on (60702848331):
Product Overview
Description
Hot sale diesel small concrete dumper with rubber crawler
PRODUCT DESCRIPTION
Mini dumper is mainly composed of hopper and walking chassis,Through material in gravity or hydraulic cylinder thrust tilting unloading.Discharge according to the different azimuth,Front to discharge,Rotary discharge,Rollover unloading,High fulcrum discharge,Lift tilting discharge and so on.
| HAOHONG Crawler truck dumper | ||||
| 1 ton | 2ton | 3ton | 4ton | |
| Total Machine Weigh | 1600KG | 1900KG | 2500KG | 3000KG |
| Engine power | 12HP Diesel engines | 32HP Diesel engines | 45HP Diesel engines | 82HP Diesel engines |
| Power | 9KW | 23KW | 33KW | 60KW |
| Pump model | 306 | 306 | 308 | 310 |
| Diesel engine capacity | 15L | 20L | 25L | 30L |
| Hydraulic volume | 3L | 5L | 5L | 7L |
| Maximum deadweight | 1000KG | 2000KG | 3000KG | 4000KG |
| Maximum grade | 30 | 30 | 30 | 30 |
| Track length | 4100mm | 4500mm | 4900mm | 5000mm |
| Track height | 550mm | 555mm | 565mm | 575mm |
| Crawler width | 350mm | 350mm | 400mm | 320mm |
| Size of the trunk | 1900*1600*1850mm | 2000*1600*1850mm | 2000*1650*1850mm | 2200*1750*1850mm |
| Machine size | 3500*1600*1850mm | 3550*1600*1850mm | 3600*1650*1850mm | 3700*1750*1850mm |
| Walking speed | 0-10km/h | 0-15km/h | 0-20km/h | 0-20km/h |
track carrier characteristics:
Free crawler transporter in mud, cicy roads,Dump design,Crawler walking,motor to walk,A great deal of extended use power.Specific size can be customized according to demand.Carrying capacity is strong,Climbing ability,simplicity of operator,Maintenance easy.
PRODUCT DETAILS
PRODUCT APPLICATION
Crawler Dumper is a frequently-used of special track vehicle , it is widely used in agriculture, minerals, water conservancy and other large and medium-sized projects for earth, rock, coal and other displacement work. Crawler transport vehicles according to their product rated capacity (load capacity) can be divided into light crawler and heavy-duty crawler.
PRODUCT SERVICE
PRODUCT INFORMATION
Hot sale diesel small concrete dumper with rubber crawler
