Антипригарное покрытие из ПТФЭ для алюминиевой сковороды, покрытие из ПТФЭ, светящаяся распылительная краска

Share on (60722275089):


Price:

Quantity:


Product Overview

Description




Product Description

Non-stick Coatings

S-200 Silicone resin non-stick coating

Description

S-200 is particularly designed for baking operation, and features extraordinarily glossy surface, outstanding stain resistance, non-stick performance and superior scratch resistance. The surface is easy to clean after baking operation. It has a very good operability, it is workable at 200, can be widely applied on the inside coating of iron bakeware.

Type

Solvent based silicone resin

Key Features

High-gloss

Excellent heat resistant

Excellent chemical resistance and abrasive resistance

Excellent and lasting non-stick performance, easy to clean

Typical Properties

Appearance

Yellowish clear liquid

Solid content (%)

35±1

Viscosity (cp)

400~800

Density (g/ml)

1.10

pH

8-10

Color of the film surface

Black with metallic

(Flat and smooth)

Curing temperature ()

280-300

Gloss (60° glossimeter)

10-20

Film thickness (μm)

15-20

Non-stick performance

Fry eggs at 170±10

>5 cycles

Corrosion resistance

Boling 3% HAc for 1 hours

No blister

Abrasion resistance 3KG/21cm2

>5000 cycles

Hardness (ZHONGHUA pencil)

3H-5H



APPLICATION

Bakeware made of aluminum, stainless and carbon steel

Storage and Handling

Available in 20 kg/ barrel or 30 kg/ barrel

Store products in tightly closed original containers at 5-35

Shelf life: 6-9 months from delivery date

How to use

1.      Requirement on pre-treatment

Firstly, apply high-temperature degreasing, then wash with 1%~3% NaOH solution (60) for more than 6 minutes. Then dry it after water rinsing;

2.      Preparation of the coating

Dispersion of coating: the coating must be fully dispersed before operation by stirring;

Viscosity adjustment: the viscosity could be adjusted according to different spray methods. Dilute with special thinner if the viscosity is over high;

Coating filtration: filtrate the coating with screen (200-400 mesh) before using.

3.      Application

The spraying environment should be dry, well-ventilated, no smoking and fire;

Use electrostatic spraying and dry out the workpieces at 100-150;

Adjust atomization and oil pump capacity of spray gun. Make sure the unit it clean and level. Keep the thickness is within 15μm-20μm;

Dry the workpieces at 280 for 5-10min.

Non-stick Type

↓ ↓ ↓ Please click product model for more informations

ModelLayerThicknessCuring temperatureNon stick propertyAnti-corrosionAbrasion resistant
  Water based fluororesin non-stick coating
PF-600225-40380-400AAAAAAAAAAAA
PF-601225-35380-400AAAAAAAAAAA
PF-602225-40380-400AAAAAAAAAAAA
PF-610320-35380-420AAAAAAAAAAAAA
PF-611320-35380-420AAAAAAAAAAAAA
PF-612320-35380-420AAAAAAAAAAAAA
  Water based ceramic non-stick coating
C-104130-45280-300AAAAAAAAAAAAAA
C-105130-45280-300AAAAAAAAAAAAAA
C-106234-50280-300AAAAAAAAAAAAAA
C-107112-20250-280AAAAAAAAAAAAAA
C-108234-50280-300AAAAAAAAAAAAAA
C-109234-50280-300AAAAAAAAAAAAAA
  Silicone resin non-stick coating
S-200115-20280-300AAAAAAAAAAAAA
S-201115-20280-300AAAAAAAAAAAAAA
S-202115-20280-300AAAAAAAAAAAAA



Our Services

OUR SERVICES:

1. Three times inspection during one production flow.

2. We can provide technical support and free samples within 500 grams.

3. We can according to the parameters given by the customer and  individual demand custom-made products that meet the customer requirement.

4. For any other question, please send them to our service Email or chat  with us online.

FAQ

 1. Q: What is your MOQ?

     A: 240 cans or 100L.

 2. Q: Can I do an OEM?

     A: Yes, we do the brand, logo as your requirements.

 3. Q: What is the how much can one litre cover?

     A: about 8-15 sqm per liter.

 4. Q: Exactly what surfaces can each type be applied to?

     A: PF-301 is used for textile, leather, shoes, etc. PF-302 is used for wood, concrete, stone, rooftile, brick etc. PF-303 is used for glass. PF-304 can be used for glass and car body.

 5. Q: Can we visit your factory?

     A: You are warmly welcomed to visit our factory, it would be our great pleasure!
