SDR-1000 мебельная полировка дерева двухсторонняя абразивная лента линейная шлифовальная машина
SDR-1000 мебельная полировка дерева двухсторонняя абразивная лента линейная шлифовальная машина
SDR-1000 мебельная полировка дерева двухсторонняя абразивная лента линейная шлифовальная машина
SDR-1000 мебельная полировка дерева двухсторонняя абразивная лента линейная шлифовальная машина
SDR-1000 мебельная полировка дерева двухсторонняя абразивная лента линейная шлифовальная машина
SDR-1000 мебельная полировка дерева двухсторонняя абразивная лента линейная шлифовальная машина
SDR-1000 мебельная полировка дерева двухсторонняя абразивная лента линейная шлифовальная машина

SDR-1000 мебельная полировка дерева двухсторонняя абразивная лента линейная шлифовальная машина

Share on:


Price:13 800,00 $ - 16 800,00 $
Price in USD:Details

Quantity:


Product Overview

Description



Product Description


This type characters:
1.double sanding machine
2.has two heads,one top,one bottom
3. sanding width between 30mm to 1000mm

-The machine is special for double-sided grinding workpiece sanding machine,with superb technology filling the gap in the market for the product,greatly reducing the expensive labor costs,reduce production cost,improving work efficiency.(Conveyor table fixed and lifting can be equipped with the production line use).






Technical Parameters
There are two types of structures, customized according to customer requirements.


Model
SDR-630
SDR-1000
Working width
20-630mm
30-1000mm
Working thickness
4-100mm
2.5-110mm
Working length
≥300mm
≥500mm
No.1#sanding belt speed
20m/s
20m/s
No.2#sanding belt speed
20m/s
20m/s
Feeding speed
2-16 m/min
4-16 m/min
Size of sanding belt(W*P)
650*1920mm
1020*2000mm
Total motor power
33.75 kw
57.5kw
Main motor power(two/four)
15kw,15kw
22kw,22kw
Working air pressure
0.55Mpa
0.55Mpa
Consumption of comperessed air
0.2m³/min
0.35m³/min
Volume of sucked air
4000m³/h
5500m³/h
Speed of sucked air
25-30 m/s
25-30 m/s
Overall dimension(L*W*H)
1900*1900*2300mm
2200*1900*2300mm
Net weight
2500kg
3300kg


Factory Video Display




Company Introduction


Qingdao Sefe Trading Co., Ltd. is a subsidiary of Sefe Woodworking Machine Manufacturing Company.
With more than 30 years of experience in woodworking and metalworking, Sefe sanding machines are well-known brands in the Chinese market, including wide belt sanding machine, paint sanding machine, water sanding machine, double-sided sanding Machine,planer sanding machine, heavy-duty inclined sanding machine and sanding machine production line.





Workshop details display


Machine Assembly Workshop
Rigorous Skilled Workers




Packing&Shipping


Stretch Film or Wooden Packing




Exhibition Show




Certifications




Why Choose Us


1. We will come standard with the wearing parts.

2. We accept the 30% TT deposit, machine will be completed within 15 to 20 days delivery.

3. We have specialized technical staff to overseas service.

4. Our warranty period is one year, if you have any questions, please communicate with us promptly.


FAQ


Q1:Why is our price more expensive than our peers?
Because we do is high-end products, accessories are high, the cost determines the price.

Q2:What is the Max working width of machine?
We recommend using standard sizes(630/700/1000/1300mm), but all our machines can be customized.

Q3:How long is the shelf life of the product? What to do if something goes wrong?
Our machines are one year shelf life, if problems arise we will allow technical staff to communicate, if necessary, will be on-site service.

Q4:How to cooperate with us?
At present, we already have distributors from many countries. Once we cooperate, we will establish a single trade relationship and work together to safeguard our interests.
