5 Gallon Blow Molding Machinery For PET/PC/PE Bottles 1 Cavity 20L Plastic Bottle Making Machine
- Category: Plastic & Rubber Machinery >>>
- Supplier: Zhangjiagang City AK Machinery Co. Ltd.
Share on (60742744267):
Product Overview
Description
5 Gallon Blow Molding Machinery For PET/PC/PE Bottles 1 Cavity 20L Plastic Bottle Making Machine
Packaging & Shipping
Features
1. Special design for PET Gallon Bottle up to 6 Gallon
2. Produce wide mouth jar up to 25 liter with neck size up to 80mm.
3. Using Infrared reheat units to achieve uniform heating throughout the wall of preform
4. Adopt special designed preform heating system to ensure the optimal heating effect for 730g thick-wall preform
5. Special designed fan-cooling system in the heating channels to keep the oven with constant temperature and ensure the preform can be heated completely.
6. Water cooling system ensures the quality of preform neck.
7. Up to 90 bottles/hour using one-cavity mold for 5-gallon bottle
TYPE | ITEM | UNIT | AK-31G |
Container | Product material | / | PET/PC/PE |
Container volume | L | 10-25 (1-cavity) | |
Theoretic output | Psc/hr | 5Gallon: 80 | |
Preform length | M | 15-460 | |
Preform inner diameter | Mm | 15-200 | |
Molding | Max mold plate dimendion (L×W) | Mm | 420×500 |
Max mold thickness | Mm | 400 | |
Clamping force | KN | 100 | |
Mold opening stroke | Mm | 330 | |
Main machine electricity | Power | M | 15 |
Voltage | V/Hz | 380-240-110/50-60(3 phase) | |
Machine size and weight | Main machine | M | 1.55×0.82×2.00 |
Main machine weight | T | 1 | |
Heater (L×W×H) | T | 2.42×0.65×1.60 | |
Heater weight | T | 0.38 |
Company Information
Q: Are you trading company or manufacturer ?
A: We are factory.
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 20 - 30 days ,if complete line it is 45-60 days.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
