512 Channel Dmx Controller Low Voltage DMX Controller With LED Display Dmx Decoder
512 Channel Dmx Controller Low-Voltage DMX Controller With LED Display Dmx Decoder

512 Channel Dmx Controller Low Voltage DMX Controller With LED Display Dmx Decoder

Share on (60769142748):


Price:

Quantity:


Product Overview

Description



Product Description


System Overview
Low-voltage DMX controller with LCD display is a kind of controller with LCD digital display interface, used for control the RGB color change of 4 line 3 channels(common anode) LED lamps and brightness change of one channel, up to 34kinds of change programs to choose, at the same time can accept DMX-512 international standard digital control. Controller can be stand-alone operation,automatically online, accept standard DMX512 console control signal etc. method to work. According to the customer's actual demand, can achieve jumpy changing, gradual changing, stroboscopic such change effect.



Technical Parameters
Working temperature: -20-60℃
Power supply voltage: DC 12～24V
Intput voltage: DC 12～24V
EXternal dimension: L190ΧW134ΧH50 mm
Packing size: L255ΧW155ΧH60 mm
Gross weight: 760g
Net weight: 585g
Static power consumption: <3.96W
Maximum output current: 8A/each channel


Detailed Images




Dimensions: L190ΧW134ΧH50 mm





1.Fence type terminal
2.XLR male port(input)
3.XLR female port(input)


1.Power supply negative pole
2.Power supply positive pole
3.Load output common positive pole
4.Load red output pole
5.Load gree output pole
6.Load blue output pole







DMX XLR interface








Product packing schematic diagram








Typical Application 1-Do not have DMX function:









Typical Application 2 -With DMX function:
