Product Overview

Description


WELCOME

DRILLING MILLING MACHINE:
Z-automatic feed milling head
Rectangular guideway on lifting platform
High stability
Hardened on X, Y, Zaxes.
Vertical head swivels +- 45 degree.
X--axis travel can be with 800mm (Optional)

\t
MODEL
\t
UNIT
\t
ZX6350ZA
\t
Spindle taper
\t

\t
MT4/ISO40
\t
Distance vertical spindle to table
\t
mm
\t
100-400
\t
Distance horizontal spindle to table
\t
mm
\t
0~300
\t
Distance spindle to column
\t
mm
\t
200~550
\t
Spindle seeds range
\t
r/min
\t
(8 steps)60-1500(vertical)
(12 steps)40-1300(horizontal)
\t
Automatic Feed Series sleeve
\t
mm
\t
120(vertical)
\t
Table size
\t
mm
\t
1250×320
\t
Table travel
\t
mm
\t
800/300/300
\t
Distance horizontal spindle to arm
\t
mm
\t
175
\t
Table feeds range(x/y)
\t
mm/min
\t
22-555(8 steps)(max.810)
\t
T of table (no./width/distance)
\t
mm
\t
3/14/70
\t
Main motor
\t
kw
\t
0.85/1.5(vertical);2.2(horizontal)
\t
Motor of table power feed
\t
w
\t
750
\t
Coolant pump motor
\t
w
\t
40
\t
N.W/G.W.
\t
kg
\t
1450/1600
\t
Overall dimension
\t
mm
\t
1700×1480×2150
