Aluminum roofing tile sheet panel roll forming making machine

Share on (60787586283):


Price:RUB 497,484.00 - RUB 663,312.00

Quantity:


Product Overview

Description

Aluminum roofing tile sheet panel roll forming making machine


Product Description

1

  Material of input sheet

 Galvanized steel/ colored steel

2

  Effective width

 840/1050mm

3

  Feeding width

 1000/1250mm

4

  Control system

  PLC control system with inverter     (Delta brand)

5

  Diameter of shaft

  70mm

6

  Material thickness

  0.2-0.8mm

7

  Motor power

  3kw

8

  Pump power

  3kw

9

  Working speed

  10-14m/min

10

  Material of cutting knives

  Cr12

11

  Material of roller

  45# steel with chrome

12

  Main frame

  300H steel

13

  Voltage

  380v 3phase 50hz

14

  Weight

  About 3 T

15

  Size

  6.0m×1.5m×1.5m

16

  Forming step

  13 steps







No.

Item

Unit

Qty

1.

Manual decoiler

set

1

2.

Main forming machine

set

1

3.

PLC Control box

set

1

4.

Hydraulic pump

set

1

5.

Cutting system

pcs

1

6.

Output table

pcs

1


Please feel free to contact us if you have any question.





.jpg

Related Products







Packaging & Shipping

Company Information





FAQ



1. Can you make the machine according to my design or photo type?

A: Yes. We have an experienced team to work out the most suitable design and production plan for the machine.


2: How can we be assured that you will deliver us quality machine with spare parts?

A:1. Customers to send the technical people to our factory for checking the quality.

   2.We can send the technicians to the buyer`s factory for the installation of the machine.


3.What policy of your garentee?

 A: Within the One-YEARS period, we could supply you the replacement parts free of charge for any damaged parts caused by quality problems after two years,you need to buy by factory cost.
