Low Noise Safety Elevator Hospital Electric Bed Goods Lift

Name: Low Noise Safety Elevator Hospital Electric Bed Goods Lift
SKU: 60810653638
Availability: InStock

Price:

Quantity:

Load goods gently and arrive at destination floor stably

1. Safe and reliable strcture and high intensity

2. Durable in use and stable in operation

3. Wide opening door and high performance cost ratio

4. Complete in specifications and excellent performance

Load	Speed	Car size			Door opening size		Shaft size				Maximum landing	Maximum lifting height	MRH mm Net height of machine room
kg	m/s	CW	CD	CH	OP	OPH	HW	HD	K	S
1000 Non-cut through type	0.5	1400	1600	2200	1300	2100	2500	2080	4200	1400	8	30	2600
	1								4400		15	60
1000 Cut through type	0.5								4200		8	30
	1								4400		15	60
2000 Non-cut through type	0.5	1700	2400	2200	1500	2100	2800	2880	4200	1400	8	30	2600
	1								4400		15	60
2000 Cut through type	0.5								4200		8	30
	1								4400		15	60
3000 Non-cut through type	0.5	2000	2800	2200	1700	2100	3250	3280	4400	1400	8	30	2600
	1								4500		15	60
3000 Cut through type	0.5								4400		8	30
	1								4500		15	60
4000 Non-cut through type	0.25	2000	3600	2400	2000	2300	3450	4080	4500	1500	4	15	2600
	0.5										8	30
4000 Cut through type	0.25										4	15
	0.5										8	30
5000 Non-cut through type	0.25	2400	3600	2400	2200	2300	3800	4080	4700	1500	4	15	2600
	0.5										8	30
5000 Cut through type	0.25										4	15
	0.5										8	30
6400 Non-cut through type	0.25	2600	4300	2400	2400	2300	4100	4780	4800	1500	4	15	2600

6400 Cut through type	0.25										4	15

8000 Non-cut through type	0.25	2700	5000	2500	2500	2400	4300	5500	5300	1600	4	15	2900

8000 Cut through type	0.25										4	15

10000 Non-cut through type	0.25	2800	6000	2500	2600	2400	4500	6500	5300	1600	4	15	2900

10000 Cut through type	0.25										4	15

VKS-H-6

_04 _06 _07
