Capability and Services Range:
1.PCB circuit layout and production
2.Plastic and metal casing design services
3.Product customized packaging design
4.SMT/SMD parts assembly and DIP through hole soldering(PCBA)
5.IC programming software(pre-programmed), PCBA functional testing and verification
6.Complete product assembly(including plastic,metal casing,PCBA motherboard,cables, swithes and other components, etc.
7.ROHS environmentally protection material supply
8.Logistics arrangements, importing and exporting goods from China
2.Plastic and metal casing design services
3.Product customized packaging design
4.SMT/SMD parts assembly and DIP through hole soldering(PCBA)
5.IC programming software(pre-programmed), PCBA functional testing and verification
6.Complete product assembly(including plastic,metal casing,PCBA motherboard,cables, swithes and other components, etc.
7.ROHS environmentally protection material supply
8.Logistics arrangements, importing and exporting goods from China
China ShenZhen is the most complete electronics manufacturing base for global electronic manufacturing services(EMS). We provide flexible and reliable electronic manufacturing solutions for customers, from parts procurement, PCBA placement , DIP soldering,PCBA testing, cabinet assembly and product testing, packing, logistics and other one-stop service. The company covers and area of 5,000 square meters, has about 200 employees, 7high-precision SMT equipment production lines, 1 DIP plug-in production line, 2 product assembly test lines, and our equipment can meet the needs of many high-precision products. As a supplier of ISO9001 quality system certification, we have accumulated rich experience in PCBA assembly and product manufacturing, and implemented strict quality management, whice makes us have a good reputation in the same industry.
PCBA Assembly Capability
(1) 7 high-speed SMT precision equipment
(2) 1 DIP through hole welding prodution line
(3) 2 assembly test production lines
(4) 1 product packging line
(5) All assemblies are ROHS compliant
PCBA Assembly Service
(1) PCBA prototype assembly
(2) PCBA batch assembly
(3) SMD surface mount technology
(4) DIP jack welding assembly
(5) BGA ball array assembly
PCB Fabrication
| NO. | Item | Specification |
| PCB Manufacturing Capabilities | ||
| 1 | PCB layers | 1 to 32 layers |
| 2 | PCB board material type | FR4,High-TG FR4,CEM-1,ALU,CEM-3,Rogers,HDI,etc. |
| 3 | Max dimension | 600 x 1200mm |
| 4 | Min line width | 0.1mm |
| 5 | Min spacing | 0.1mm |
| 6 | Dimension tolerance | ±0.1mm |
| 7 | Min hole diameter | 0.2mm |
| 8 | Pcb board thickness coverage | 0.2 to 6.0mm |
| 9 | Min copper thickness in hole | 0.02mm |
| 10 | DK thickness | 0.08 to 6.0mm |
| 11 | NPTH size tolerance | ±0.025mm |
| 12 | PTH size tolerance | ±0.025mm |
| 13 | Dimension tolerance | ±0.1mm |
| 14 | Hole position tolerance | 0.075mm |
| 15 | Laser drill hole size | 0.1mm |
| 16 | Min soler mask | 0.01mm |
| 17 | Minimum size of solder mask separation ring | 0.05mm |
| 18 | Max board twist and wrap | ≤1% |
| 19 | Finished hole diameter | 0.2 to 6.0mm |
| 20 | Flame resistance | 94V-0 |
| 21 | Impedance control tolerance | ±5% |
| 22 | Outer layer copper thickness | 8.75 to 175um |
| 23 | Inner layer copper thickness | 17.5 to 175um |
| 24 | Solder mask type | Blue,Green,Black,Yellow,Red,White |
| 25 | Surface finish | HASL,OSP, ENIG, Gold plating,Immersion Tin,etc. |
Workshop Show
Workshop Show
Packing & Delivery
Packing & Delivery
FAQ
FAQ
Q1, who are we? Why choose us?
A1: We are an electronics manufacturing services (EMS) supplier, we provide customers with flexible and reliable electronic manufacturing solutions, from parts procurement, (board) PCBA processing, DIP through-hole soldering, PCBA testing, cabinet assembly and One-stop electronic manufacturing services such as product testing, packaging, and logistics.
A2: With a variety of different product introduction experience, we have established a team of perfect ISO9001 quality system certification, including: human resources, marketing department, project management, engineering technology, PMC procurement, quality management, production, warehouse management And many other departments.
Q2, what information do we need to provide in order to get an accurate quote quickly?
A: The more detailed the product data and requirements are, the faster and more accurate the quotation will be, such as:
1.PCB manufacturing: Gerber files or PCB files
2.PCBA manufacturing: Gerber files, BOM bill of materials.
3.PCB requirements for sheet metal, thickness, copper thickness, tin spray, immersion gold, silk screen color, sheet color and other documents.
4.Comprehensive and detailed BOM bill of materials, including: part number, usage, specific specifications, parts manufacturers.
5.Replaceable parts, confirm approved spare parts.
6.PCBA IC pre-programming, providing software burning test version, test method.
7.PCBA or product assembly requirements, providing specific executable files.
8.If plastic, metal, cable, packaging, etc. are required, a document drawing that can be produced is required.
9.For other special requirements, a schematic document is required.
Q3, what is the minimum requirement for the order?
A: We support customers to arrange the order quantity according to their own needs. There is no minimum quantity limit. Of course, the more orders, the more competitive the price competition.
Q4, How long is your order production time?
A: According to the complexity and simplicity of the product, when the parts are ready, we need 3-10 working days to prepare all the components.
Q5, can we visit your factory?
A: Our production facilities are always welcomed by customers. Please call us at +086-0755-27780875
or Email: marketing001 at meizenta.com. We will make an appointment for you to visit the factory.
