115v/230v DC motor speed controller 90v/180v dc motor controller  Model:115/230DR10AL-02

MMT-115/230DR Series DC motor driver is a kind of speed governing product developed and produced by adopting past successful experience and combining modern advanced technology. This series of products have met international standard requirements and are sold to many countries. This driver adopts thyristor chopping control principle and uses independent trigger mode. Even there is no velocity feedback, high speed ratio can be achieved to make it more accurate and reliable.

Excellent performance, reliable quality and high cost performance make it a strong performer in DC motor driver field and it was widely used in plastic machinery, food machinery, cable equipment, machining, paper printing, testing equipment, laboratory equipment and mixing equipment, etc.

Specification and model:

 Model                     Max. output current  Max. output voltage  Input voltage range

                                DC: (A)                     DC: (V)                  AC: (V)

90/180DR10BL-01       10                      90/180                    115/230

90/180DR10AL-01       10                      90/180                    115/230

115/230DR10BL-01      10                     115/230                  115/230

115/230DR10BL-01      10                     115/230                  115/230



 1



Product type

Continuous operation

Non-isolated type/isolated type

Output current

Thyristor speed regulation

DC output

Max. output voltage

Technical parameters:

1.input voltage AC: 115V/230V±10% (other voltages can be customized as customer’s requirements)

2.frequency: 50/60HZ±5%

3.output voltage DC: 0~90V   0-110V   0-160V   0-180V   0-220V (can be set)

4.rated output current: 10A

5.revolving speed ratio: 80:1

6.output voltage accuracy: ≤0.1%

7.soft starting time: 0.2S-20S

8.soft stopping time: 0.2S-10S

9.environment temperature: -10℃~+60

10.environment humidity: relative humidity ≤65% (no moisture condensation)

11.insulation voltage resistance: 1500V AC

12.insulation resistance: >500MΩ

13.leak current: ≤0.09mA

Dimension
115 230DR10AL-02
L*W*H=116*103*48mm


Related Products

 scr

Our company

 servo motor workshop

Jinan Keya Electronic science and technology Co. has been in research and development, manufacturing and sales of DC motors for more than 10 years with more than 100 employers and a lot of advanced eqipment.

Our Certifications

 _

The company has adtoped ISO9001:2008 quality management system certification, some products have passed CE certification and won good reputation from our customers at home and abroad.





Application

 2

Packaging

 dc controller kit

We pay high attention to the Motor packaging, adopt polyfoam packing and then fill them to carbon to protect the controller, this series of complete packing enable you receive good products.

FAQ



Q: What kind motors you can provide?

A: For now, we mainly provide permanent magnet brushed dc motors (including low power and high power dc motors) with power range in  20~5000w.



Q: Is there a MOQ for your motor controller?

A:  There is no MOQ requirement. But the more the better.



Q: How do you ensure the product quality?

A: We have strict test system in every link of material selection, production and final product, packing according to ISO9001 management.



Q: Is it possible for you to develop new controllers if we provide the tooling cost?

A: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we'll make our evaluation to see if we can arrange or not.



Q:How to Contact Us?

A: Send your Inquiry in the Below for Detail Information, Click ' Send ' Now!
