3 Liter Dental Tool Cleaning Digital Heated Ultrasonic Cleaner (62076523780)

Share on (62076523780):


Price:$155.00
Price in USD:Details

Quantity:


Product Overview

Description


Product Description
Digital Heated Ultrasonic Cleaner

CAVITATION *

knowledge about ultrasonic cleaning and that the ultrasonic

generator and transducer are required to produce cavitation in an ultrasonic cleaning bath and that it is the scrubbing force found in ultrasonic cleaning, how is it formed?

To develop a cavitation event we must transmit a high intensity pressure wave from the transducer into a liquid with enough amplitude so as to tear the liquid apart in the rarefaction half cycle and drop the pressure

within the liquid below its point of vaporization. When this has been achieved we will develop millions of minute vacuum bubbles called cavitation events. Every half cycle we develop these vacuum bubbles which store their developing energy and then collapse or implode in the compression half cycle releasing their energy. This causes the shear forces they release to break the bonds holding a particle to the item being cleaned. At 40 KHz this cleaning cycle will repeat itself 40,000 times a second.



What is ultrasonic cleaning?

Ultrasonic cleaning is an exceptional technique that facilitates the cleaning process. It is an exceptionally thorough process which cleans efficiently various items. This powerful process can perform very detailed work quickly and successfully remove microscopic particles from hard surfaces. External as well as internal surfaces, blind holes and crevices, can be cleaned simultaneously and uniformly. Greasy, oily and sticky parts are efficiently cleaned with an ultrasonic cleaning unit.



In order to protect users, preserve data and keep society running smoothly, it’s very important for electronics of all types to not just be regularly cleaned, but cleaned thoroughly.

  1. Car service: Flushing carburetors, injectors, injectors, fuel filter mesh cleaning (petrol), individual parts, assemblies, and entire blocks.
  2. Medicine: Washing and polishing of optics, sterilization and cleaning of surgical instruments, vials, dental and pharmaceutical industries; cleaner reusable, molds.
  3. Engineering: Cleaning of parts, pipes, wires, etc. before finishing, machining parts and components to the preservation, processing of parts after reopening, welding, grinding, polishing, cleaning strainers in the fuel and hydraulic systems, deburring parts.
  4. Instrumentation: Washing and polishing of optics, precision mechanics components, integrated circuits and printed circuit boards.
  • Enhance Your Cleaning Process with Ultrasonics
  • Ultrasonic cleaning has become increasingly popular year after year. One reason is that it's an environmentally friendly process capable of replacing some vapor degreasing processes. The second is that it enhances aqueous cleaning processes in many applications...

Ultras Wave Explanation

Pressure waves generated by high-frequency sound waves create micron-size bubbles in the aqueous cleaning solution. This bubble is shown just before implosion, which releases a tremendous amount of energy for cleaning



Other models for your choice:

ModelTank sizeUnit sizeVolumeActual ultrasonic powerRated ultrasonic powerUltrasonic frequencyHeating powerTimerHeating temperature
LxWxH(mm)LxWxH(mm)(L)(W)(W)(kHz)(W)(MIN)(℃)
TB-50150x135x100175x160x21025060401501-300-80
TB-100240x135x100265x165x2203.2100120150
TB-150A300x150x100325x180x2254.5150180300
TB-150B300x150x150325x180x2806.5150180300
TB-200300x240x150325x265x28010.8200240450
TB-300330x300x150360x325x28515300360450
TB-400500x300x150530x325x28522400480600
TB-500500x300x200530x325x32530500600600


Features:


1. Ultrasonic power: 0-100% adjustable

2. Time setting: 0-30min or 24 hours continuous working

3. Heating: 20-80℃ adjustable

4: Ultrasonic frequency: 28 kHz or 40 kHz

5: Material: 2mm thickness SUS304 tank for acid-proof.

6: Improved PCB design for stable and durable industrial use

7: More strong and uniform ultrasonic wave

8: With free lid and stainless steel SUS304 basket



Shipping:

we have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Post
You also can choose your own shipping forwarder

Ultrasonics: The ONLY Way to Clean with Confidence

Regardless of the source of the dirt or contamination, AG Ultrasonic Cleaning Systems are designed to accommodate a wide variety of uses in diverse industries. Fast, effective and efficient, our machines will allow you to clean virtually any type of part or component. The following is just a short list of the many different types of items that have been cleaned using our systems.

  • Automotive (Car, Truck, Motorcycle) See Video Below
  • Aviation (Helicopters, Aircraft and Ground Support)
  • Personal Boat & Marine
  • Injection Molds
  • Restaurants, Bakeries & Kitchens (Oven Filters, Burners, Pots, Pans, Utensils)
  • Machines of All Types
  • Tools, Nuts, Bolts
  • Extrusion and Deburring
  • Almost anything made out of metal (ferrous and non-ferrous), plastic, vinyl, and wood.

Cavitation provides an intense scrubbing action that leads to quick and consistent cleaning. It takes the standard practice of manual immersion and agitation to a much higher level. The bubbles are small enough to penetrate even microscopic crevices, allowing for cleaning in the most out-of-reach corners.

•Low maintainence machine
•Heavy duty cleaning systems
•Chemical friendly- SS Rust proof body
•Industrial guage farication, build to last
•One year warrenty on any manufacturing defect
•Completely customized to suit the cleaning requirement
•Less human interfearance and less scope of error
•Accurate and uniform cleaning everytime

3 (3).jpg3 (2).jpg

6 (5).jpg





Packaging & Shipping
Shipping:

For 1pcs or small quantity, shipping by express/air is suggested.

For laege quantity, shipping by sea is cost-effective.

We have cooperated forwarder, welcome to ask freight.

Company Information

AG SONIC technology limited, which engaged in ultrasonic cleaner field for more than 10 years. And the main products are ultrasonic cleaner with different capacity.

AGSONIC ultrasonic cleaners are all designed, manufactured and tested to the highest standards. This is further supported by the 2 year warranty we offer on our ultrasonic cleaning equipment.



AGSONIC can offer solutions to every cleaning requirement.

Ultrasonic Cleaners are used in various industries from Automotive to Electronics to Medical facilities for a number of applications.

---_02

workshop 2

Our Services

Our service:

1. Any Inquiries will be replied within 24 hours
2. Professional manufacturer. Welcome to visit our website.
3. OEM/ODM available:
1).Silk print logo on the product;
2).Customized product housing;
3).Customized Color box;

FAQ

Q: Why is Ultrasonic Cleaning so Efficient and Effect?

A: When cavitation happens near a dirty object, the vacuum action produced by those million of bubbles constantly imploding creates a tiny pressure wave that reaches deep into every nook and cranny of even the most delicate items.

This tiny pressure wave dislodges and breaks up the dirt and other contaminants and gently lifts it away. The result isvery fast and effective cleaning.

Ultrasonic Cleaning Step :

Place your disassembled motor boat engine components in the cleaner’s mesh basket. Position them to avoid contact with each other.
Place the parts basket into the heated bath. Cleaning time will vary depending on the condition of the parts but you can start at 40 minutes. Use this time to handle other chores.

At the end of the cycle remove the basket and inspect the parts for cleanliness. If you are not happy replace them in the bath for another run. A caution: do not reach into an operating ultrasonic bath.

When parts are clean, rinse them in fresh water to remove the ultrasonic cleaning solution residue. Allow them to dry and lubricate or oil as needed before reassembly.



What is the length of cleaning time?

Cleaning time will vary, depending on such things as soil, solution, temperature and the degree of cleanliness desired. Highly visible removal of soils should start almost immediately after the ultrasonic cleaning action begins. Cleaning time adjustment is the easiest (and most often misapplied) factor used to compensate for process variables. Although new application cycle duration can be approximated by an experienced operator, it usually must be validated by actual use with the chosen solution and the actual soiled parts.

What is the purpose of the unit heater?

The primary purpose of the unit heater is to maintain a solution temperature between cleaning cycles. The tremendous energy released by cavitation will generate the heat for cleaning.

Why must baskets be used?

Items being cleaned should never be placed directly on the tank bottom. Transducers (which produce the ultrasound) are sometimes bonded to the bottom of the tank. Items resting directly on the tank bottom can damage the transducers and/or reduce cavitation. Additionally, a tray or beaker will position the item within the optimal cleaning zone of the tank. The tray or beaker will also hold the load together and allow for easy, no-touch removal, draining and transport of the items to the next step in the cleaning process

What is the optimum cleaning temperature?

Heat usually enhances and speeds up the cleaning process, and most detergent solutions are designed to work best at an elevated temperature. The best way to find the optimum temperature, which will give you the fastest, cleanest and safest results, is to run tests. Usually, the best results are within the 50°C to 75°C range.

Understanding Ultrasonic Power

When an ultrasonic cleaner is running electrical power is consumed evenly but it is released in intervals to create the sound waves that shape the ultrasonic signal. Some manufacturers report ultrasonic peak power, others report average power, and some report both.

When comparing equipment you must compare based on the same criterion otherwise you’d be comparing apples with oranges.

While more power usually indicates faster and more effective cleaning, more power is not always better.

Too much power can damage electronic parts, the surface finish on a soft metal (e.g. aluminum), and other delicate items.

For cleaning extremely sensitive items, adjustable power is a useful feature.

Keep in mind that the larger the volume of solution, the more ultrasonic power will be needed for cleaning.

Most cleaners run at an average power of 50 to 100 watts per gallon, so the larger the tank the more power you need.Don’t attempt to increase the effective power of an ultrasonic cleaner by under-filling the tank.
