6.Thermometer (According to customer requirements ).
7.Paddle blender .(According to customer requirements).
8.Liquid level meter and lever controller (According to customer requirements) .
9.Platform
Extractor is applicable to the project operations of water decoating under normal and compressed pressure, temperature dipping, thermal refluxing, forced circulation, diacolation, extraction of aroma oil and reclamation of organic solvent,etc, which are in such industries as Chinese traditional medicine, plants, food and chemistry.
Techanical Parameter
Specifications
Volume
(L)
Design pressure tank(Mpa)
Design pressure jacket(Mpa)
Diameter of residue discharging door(mm)
heating area
(m2)
condensing area
(m2)
cooling area
(m2)
Filtering area
(m2)
LNT-1T
1200L
0.09
0.3
600mm
3
6
1
3
LNT-2T
2300L
0.09
0.3
800mm
4.7
10
1
3
LNT-3T
3200L
0.09
0.3
1000mm
6
12
1.5
3
LNT-6T
6300L
0.09
0.3
1200mm
7.5
15
2
5
LNT-8T
8500L
0.09
0.3
1200mm
9.5
18
2
5
LNT-10T
11000L
0.09
0.3
1200mm
12
20
2
6
We can customize the equipment according to customer requirements.
More details picture
Process Flow Chart
Package flow chart
Company Strength
More Related Products:
FAQ
1.Q:Are you trade or manufacturer ? A : We are a factory with an international sales company specialized in support for global distributors.
2.Q:How long is the service time? A:It could use several year without external force factors.We have 1 year warranty.
3.Q:What is the payment terms? A:We accept T/T and L/C,also can use alibaba trade assurance.
4.Q:How to choose the shipment way? A:It is according to the order quantity,delivery time,costs and customs policy,etc.(Or decide by customers).
5.Q:How about the surface finishing? A:Machine finished,matt and mirror polished,it will be confirmed by customer requirements.
