New 03054491 CR5D00E2MC7B 2 Port 40GBase LAN CFP Integrated Line Processing Unit B(LPUI 101 B) for NE40E
- Category: >>>
- Supplier: Shenzhen Cool Life Technology Co. Ltd.
Share on (62103043819):
Product Overview
Description
Product Description
unctional Specifications
Table 6 Functions and features
Functions and Features | Remarks |
|---|---|
Line-Rate capability | Supports 100G line-rate forwarding. It supports two 40G interfaces for line-rate forwarding. |
Reliability and availability | Hot swappable. |
Whether breakout is supported | No |
Technical Specifications
Table 7 Interface specifications
Attribute | Description |
|---|---|
Optical type supported | |
Working mode | Full-duplex |
Compliant standard | IEEE 802.3 |
Frame format | Ethernet_II, Ethernet_SAP and Ethernet_SNAP |
Table 8 Board specifications
Item | Specification |
|---|---|
Dimensions (H x W x D) | 40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x 21.09 in.) |
Typical power consumption | 316.0 W |
Typical heat dissipation | 1025.2 BTU/hour |
Weight | 9.1 kg (20.07 lb) |
Ambient temperature | Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms: -5 °C to 55 °C (23°F to 131°F) |
Packaging & Shipping
Packing Detail : Huawei orignal packing
- Port : Shenzhen
- Lead Time : 7days
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Warranty
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed Huawei product: 1 Year
The Support Contacts:
If your Huawei products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Company Information
Uonel is one of the biggest Huawei Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Huawei Routers, Switches,Firewalls, Wireless APs & controllers, OLTs,GPON modems, optical transceivers. Our company have more than $5million Huawei products in stock.
Most of our technical engineers had work exprience in Huawei company, we can provide network design&planning, configration, troubleshooting, maintenance and training service in world wide.
