M3 M12 Автоматическая сверлильная и нарезающая машина

Product Overview

Description

         M3-M12 Automatic Drilling And Tapping Machine



Product Description

The product is suitable for work piece material:

Electric tapping machine can be easy to tap in lead, copper, steel, cast iron, pig iron, 45 steel, die steel, metal material and other metal materials.

Applicable to all machinery manufacturing industry, machine tools, mold machinery, printing machinery, packaging machinery manufacturing plants, construction machinery, rolling stock, aircraft engines, plastic machinery and general machinery and other industries.

Details

1.The tapping motor of the tapping machine is suspended and supported to balance and vertical. The support frame can make the tapping motor move to any position, and it can keep perpendicular to the worktable.

2.The serpentine plastic wire and conduit protects the circuit and does not affect the rotation of the body.

3.The flexible steering shaft, high rigid frame support, has excellent support for precision and processing stability.

4.High thicknesses of insulating rubber for the pedestal support ensures the flexibility of the power supply and ensures the flexibility of the entire working rod.

Technical Parameters

Condition	New
CNC or Not	Normal
Drilling Speed	400rpm/min
Power(W)	800
Dimension(L*W*H)	60*59*58cm
Weight	20kgs
Certification	CE
After-sales Service Provided	Overseas service center available
Tapping Capacity	M3-M12
Spindle speed	500rpm/min
Working Radius	1100mm
torque chuck/collet	6pcs
Tapping Direction	90degree
Guarantee	18months
Weight	20kgs
Color	Blue and white
Worktable	No
Quick change adapter	Yes



Packaging and shipping

Packing:Standard Export Packing;

Shipping:delivery within 7 working days.



Application

This pneumatic tapping machine is applicable to all machinery manufacturing industry, machine tools, tooling machinery,plastic machinery, printing machinery, packaging machinery, engineering machinery, automobile and motorcycle parts,aircraft engines and other general purpose machinery industries.The tapping range is: M6to M30.



Feature

1 . High quality electric tapping machine, high speed with low torque, low speed with high torque, and have the protection of over voltage, over current, over load, etc.

2. Touch layer design, automatic or manual options, easy operation. With the high efficiency, saving time and energy, accurate positioning, fast cutting.

3. Tap shall never break for tapping trough-hole or blind-hole.



Services
1.According to your inquiry, We will reply to you in 24 hours.

2.Best After-sales: We will send the technical personnel to the site for installation, commissioning and training work.

3.Warranty period 12 Months, in addition to the force majeure and man-made factors, the damage caused by design, process and manufacturing equipment, the seller is responsible for sending people to offer free repair.

4.We will send the spare parts as soon as possible when necessary, equipment repair parts provided by the seller are original, authentic, quality goods.



FAQ

Q: How long is your delivery time?

A: Generally it is 3-7 days if the machines are in stock. It is 10-15 days if not in stock, it is according to quantity.

Q: Do you offer sample?

A: We could offer the sample in cheaper price but exclude the freight.

Q: The operating interface is in Chinese or English?

A: Normal, our tapping machine is Chinese-English switching interface, we also can make All-English type

according to the customer's request.

Q: Taps arc arc included in the package?

A: Taps are excluded in our package.we can equip chucks according our customers' requirements.

Q: What kind of chucks are included in your package?

A: We have three types: ISO/JIS/British type in stock, you can chose one type from the three. If there is no

special requirements, we will send ISO chuck.

Q: Product warranty?

A: 12 months after payment.from the three. If there is no special requirements, we will send ISO chuck.



Contact us

Thanks for watching, and look forward to cooperating with you.

If you are interested in our tapping machine price.
Please don't hesitated to contact us.Your inquiry will be highly appreciated.
