High quality bwd cycloidal vertical gear motor xwd2 cycloidal gearbox

Introduce

X/B cycloidal pinwheel reducer is a kind of machinery which implements reduction by meshing cycloidal pinwheel teeth according to the principle of planetary transmission with few tooth difference. This machine can be divided into horizontal, vertical, biaxial and direct assembly modes. It is a common equipment for metallurgy, mining, construction, chemical industry, textile and light industry.

sturcture and principle

Cycloidal gear reducer is a new transmission device with planetary transmission principle and cycloidal gear meshing. All transmission devices of cycloidal pinwheel reducer can be divided into three parts: input part, deceleration part and output part.

Dislocation on the input shaft is equipped with a 180 ° of the double eccentric sleeve, turn on the eccentric sleeve is equipped with two called arm of roller bearing, the formation of H, two cycloid gear center hole is the eccentric sleeve on the turning arm bearing raceway, and by a group of cycloid gear and pin gear mesh circular permutation needle, to form tooth difference, for the internal meshing gear reducer is institutions (in order to reduce friction, in small ratio of speed reducer, the needle with needle teeth on the gear set).
