Wastewater evaporators price
US $7800
Падение пленки низкой температуры конопли КБР il испаритель
- Category: Evaporator >>>
- Supplier: Suzhou Pharma Machinery Co. Ltd.
Share on (62254406958):
Product Overview
Description
Product Description
1.Evaporation Temperature:40℃~70℃.
2.Steam Pressure:0~0.3Mpa Cooling Water circulation temperature (In20℃ Out 25℃)
3.Processing Ability:Cloud remove 80-95% alcohol from liquid.
4.Machine Material:Contact part all SUS 304.
5.Machine Voltage:As customer required.
6.Operator quantity required:1
7.Heating Method:Steam heating(Recommend)
8.Evaporation Mode:Liquid be film to increase the evaporation area by falling drop.
9.The main features:
The equipment system operates under negative pressure, with continuous feeding and discharging, heating and evaporation time is short, and it is suitable for evaporation and concentration of heat sensitive materials.
The material is evaporated under vacuum in a fully sealed system, and the concentrated liquid is pollution-free.
The top cover of the heater is equipped with quick-opening device for easy cleaning.
The equipment has compact structure, small floor area and simple operation
2.Steam Pressure:0~0.3Mpa Cooling Water circulation temperature (In20℃ Out 25℃)
3.Processing Ability:Cloud remove 80-95% alcohol from liquid.
4.Machine Material:Contact part all SUS 304.
5.Machine Voltage:As customer required.
6.Operator quantity required:1
7.Heating Method:Steam heating(Recommend)
8.Evaporation Mode:Liquid be film to increase the evaporation area by falling drop.
9.The main features:
The equipment system operates under negative pressure, with continuous feeding and discharging, heating and evaporation time is short, and it is suitable for evaporation and concentration of heat sensitive materials.
The material is evaporated under vacuum in a fully sealed system, and the concentrated liquid is pollution-free.
The top cover of the heater is equipped with quick-opening device for easy cleaning.
The equipment has compact structure, small floor area and simple operation
Mode | SHF-30 | SHF-45 | SHF-70 | SHF-100 | SHF-160 | ||||
Evaporation Ability | 100-120L /H | 160-180L /H | 250-280L/H | 370-400L/H | 600-650L/H | ||||
Evaporation Temperature | 45-80℃ | ||||||||
Heating Resource | Steam Heating(Recommand) | ||||||||
