【General technical Parameter】 | ||||||
Brand | Howo | Type | ZZ3317N386GE1 | |||
Gross weight (Kg) | 31000 | |||||
Rated load (Kg) | 15770 | Dimension (mm) | 9880×2496×3450 | |||
Curb weight (Kg) | 15100 | Cargo dimension(mm) | 7200×2300×1100 | |||
Passenger | 2 | Utilization factor of Payload | 1.05 | |||
Approach/ Departure angle(°) | 19/24 | F/R Overhang (mm) | 1430/1800 | |||
Axle number | 4 | Wheel basemm) | 1800+3500+1350 | |||
Axle load(Kg) | 6500/7000/17500 | Max speed (Km/h) | 82 | |||
其它 | 1. Rear load and discharge. 2. Side protection material: Q235A steel plate, bolt connection Rear protection material: Q235A steel plate, bolt connection, Cross- section dimension: 100mm*100mm, Ground clearance:530mm 3. ABS type: 4460046300 4.Driving data recorder with GPS | |||||
Chassis Technical Parameter | ||||||
Chassis type | ZZ3317N386GE1 | Name | Dump truck chassis(2nd class) | |||
Brand | Howo | Manufacturer | CNHTC Jinan Truck Co., Ltd. | |||
Chassis dimension (mm) | 9080×2496×3105 | Tyre number | 12 | |||
Approach/Departure angle (°) | 19/44 | Tyre specification | 11.00R20 | |||
Steel plate spring number | 11/11/10,11/11/- | Front tread(mm) | 2020/2020 | |||
Fuel type | Diesel/LNG/CNG | Rear tread(mm) | 1830/1830 | |||
Emission standard | Euro 5 | |||||
Engine type | MC07.28-50 | Displacement (ml) | 6870 | |||
Horsepower | 280 | |||||
