China advanced small pyrolysis systems Waste plastic to diesel device
By the process of Pyrolysis, plastics can be converted into fuel and in most scenarios three major products are obtained at the end of the process. These products are Pyrolysis Oil, Carbon Black and a Gaseous mixture. All these three are arranged in order of their composition in the product. The properties of pyrolysis oil can be improved by hydrogenation.
Output product and application
1
Tyre oil
50%
• can be sell directly.
• make diesel and gasoline by used oil distillation machine.
•can be as fuel.
2
Carbon black
30%
• can be sell directly.
• make fine carbon by the carbon black grinding equipment.
• make carbon brick by briquetting equipment.
3
Steel wire
12%
• can be sell directly.
• make steel bloom by hydraulic press-packing
4
Combustible gas
8%
• can be as fuel heating the reactor
• extra gas also be storage as fuel for other heating.
After-sales Service:
1) Production with our automatic production line.
2) Quality Inspection;
3) Transportation to seaport and loading into containers:
4) Installation and Commissioning:
5) Worker training:
6) 12 months' Quality Warranty from the date of successful commissioning.
Technical parameter
Item
Contents
Input-Raw Materials
Waste tire/rubber/Medical waste/MSW
By-products
Fuel oil, carbon black, steel wire, syngas
Model
Reactor size
Capacity
HY2200*5500
5 Ton/Batch
HY2200*7500
7 Ton/Batch
HY2600*6600
8 Ton/Batch
HY2800*6000
9 Ton/Batch
HY2800*6600
10 Ton/Batch
Reactor material
Q345R/Q245R/310S+Boiler plate/Stainless steel
Thickness
14mm/16mm/18mm
Weight
15T-35T
Power
Average 15KW/h
Space needed
300-400 square meters (Width:10m, Length:30m-40m)
Labor needed
3-4 workers
Density of oil
0.89g/cm3
Combustion value
44.30KJ/KG
Note:
We supply customized mini plant: 10kg plant, 1ton plant for customer trial operation.
Company Information
Xinxiang Huayin Renewable Energy Equipment Co., Ltd located in xinxiang city , Henan Province ,we are a producer and seller specialized in research, development, production of waste tire/ plastic pyrolysis plant , waste engine oil /pyrolysis oil distillation to diesel plant , waste oil sludge treatment equipment. We have complete machining equipment, perfect process flow, powerful technical strength, excellent product development and design capability as well as rich production experience. Our company has been certificated to ISO9001 and CE international quality management system. Thanks to our excellent product quality and good after-sales service, our ptroducts have been exported far to European Union, Asia, Southest Asia , Africa , USA .
For more details , welcome send us inquiry to get more details .
