Commercial Drying Freezer Equipment Flower Lyophilization Dehydration Processing
- Category: Vacuum Drying Equipment >>>
- Supplier: Hangzhou Ouhui Machinery Co. Ltd.
Share on (62375832026):
Product Overview
Description
Product Description
Freeze dryer for food industry
Ouhui FD series freeze dryer is a batch freeze dryer.
It is suitable for industrial production in food factories.
Raw materials are pre-frozen to below - 18 degrees by an external special quick-freezing device.
Applicable to all kinds of vegetables, fruits, meat, all kinds of conditioning food, health products, etc.
Basic specifications
| Style | Dry area | Material | Dehydration | Drting bin size | Tray size | Tray | Mode | Cart | HeatLayer | Power KW | Steam | Coldloss KW | Comp air | Water Kg/Hour | Gen power | Total size(m) |
| FD-1 | 1 | 30L | 2Kg/Hour | 600*1100 | 870*390*33 | 3 | Manual | 3+1 | 2.1 | 1.8 | 3.5 | 7.7KW | 2.1*2.1*1.9 | |||
| FD-2 | 2.3 | 60 | 4 | 800*1135 | 870*540*33 | 5 | 5+1 | 4.2 | 3.8 | 3.5Kg | 10.3 | 2.3*2.1*2.1 | ||||
| FD-3 | 3.3 | 90 | 6 | 1000*1370 | 7 | 7+1 | 6.3 | 5.7 | 5 | 15.8 | 2.5*2.2*2.3 | |||||
| FD-5 | 5.6 | 150 | 10 | 1200*1470 | 11 | 11+1 | 10.5 | 9.5 | 0.1M3/Min | 5 | 26 | 4.1*2.0*2.3 | ||||
| FD-10 | 11.3 | 300 | 20 | 1800*1770 | 24 | Auto | 1 | 12+1 | 21 | 19 | 0.2 | 15 | 49 | 9*8*2.8 | ||
| FD-20 | 22.6 | 600 | 40 | 1800*2670 | 48 | 2 | 12+1 | 42 | 38 | 0.4 | 225 | 97 | 9*10*3.0 | |||
| FD-30 | 33.8 | 900 | 60 | 1800*3570 | 72 | 3 | 12+1 | 100 | 57 | 0.4 | 300 | 73 | 9*12*3.0 | |||
| FD-50 | 50.7 | 1500 | 100 | 2400*3900 | 108 | 3 | 18+1 | 160 | 97 | 0.7 | 450 | 137 | 11*13*3.7 | |||
| FD-100 | 101.5 | 3000 | 200 | 2400*6600 | 216 | 6 | 18+1 | 320 | 193 | 0.9 | 900 | 255 | 11*16*4.1 | |||
| FD-150 | 152.2 | 4500 | 300 | 2400*9300 | 324 | 9 | 18+1 | 480 | 291 | 0.9 | 1500 | 338 | 11*18*4.1 | |||
| FD-200 | 203 | 6000 | 400 | 2400*12100 | 432 | 12 | 18+1 | 630 | 387 | 1.3 | 2200 | 457 | 11*21*4.1 |
