Flue gas O2 | |
Technical data | |
Measuring range | 0 to 21 Vol.% |
Accuracy | ±0.2 Vol.% |
Resolution | 0.1 Vol.% |
Reaction time | 30 s |
Flue gas Draught | |
Technical data | |
Measuring range | -20 to +20 hPa |
Accuracy | ±0.03 hPa (-3.00 to +3.00 hPa) |
±1.5 % of mv (Remaining Range) | |
Resolution | 0.01 hPa |
Flue gas degree of effectivity, Eta (calculated) | |
Technical data | |
Measuring range | 0 to 120 % |
Resolution | 0.10% |
Flue gas loss (calculated) | |
Technical data | |
Measuring range | 0 to 99.9 % |
Resolution | 0.10% |
Flue gas CO2 calculation (calculated from O2) | |
Measuring range | 0 to CO2 max (Display range) |
Accuracy | ±0.2 Vol.% |
Resolution | 0.1 Vol.% |
Reaction time | < 40 s |
Pressure measurement | |
Measuring range | -40 to +40 hPa |
Accuracy | ±0.5 hPa |
Resolution | 0.1 hPa |
Flue gas CO (without H2-compensation) | |
Measuring range | 0 to 4000 ppm |
Accuracy | ±20 ppm (0 to 400 ppm) |
±5 % of mv (401 to 2000 ppm) | |
±10 % of mv (2001 to 4000 ppm) | |
Resolution | 1 ppm |
Reaction time | 60 s |
Ambient CO | |
Measuring range | 0 to 4000 ppm |
Accuracy | ±20 ppm (0 to 400 ppm) |
±5 % of mv (401 to 2000 ppm) | |
±10 % of mv (2001 to 4000 ppm) | |
Resolution | 1 ppm |
Reaction time | 60 s |
1. Original and brandnew in stock with two years warranty
2. Direct CO,O2,flue gas,temperature,air,pressure measurement
3. Quick sensor zero in 30 seconds

For small items, we will fully pack with Yellow Tape to protect water.For standard carton we will pack with stretch film and psate with client's shipping mark mentioning company name,carton number.
We have all items in stock, for sample we can send out within 3 working days, for OEM we can send within 35 working days,mosty depends on the quantity and our sales season!
