0.5 to 200m2 Industrial Food Freeze Dryer Fruit Dehydrator
US $25000-$28000
Лабораторное оборудование лиофилизатор или лиофилайзер лиофилизация в микробиологии сушилки для замораживания канифоли
- Category: Freeze Drying Equipment >>>
- Supplier: Nanjing,Gengchen,Scientific,Instrument,Co.,Ltd.
Share on:
Product Overview
Description
Lab Equipment freeze dryer candy lyophilizer buy lyophilization bacteria
Model | Biosafer-12A (ordinary type) | Biosafer-12B (gland type) | Biosafer-12C (Manifold ordinary type) | Biosafer-12D (manifold gland type) |
Clod trap temp | -50/-80 ℃ | -50/-80 ℃ | -50/-80 ℃ | -50/-80 ℃ |
Vacuum degree | ||||
Freeze dry area | 0.12-0.18 m² | 0.075 m² | 0.12-0.18 m² | 0.075 m² |
Water capture capacity | 4 kg/24h | 4 kg/24h | 4 kg/24h | 4 kg/24h |
Load materials | 1200-1800 ml | 750 ml | 1200-1800 ml | 750 ml |
Material tray specification | 200*20 Φ*h mm | 180*20 Φ*h mm | 180*20 Φ*h mm | 180*20 Φ*h mm |
Material tray layer | 4-6 layer | 3 layer | 4-6 layer | 3 layer |
Freeze drying time | 24 h | 24 h | 24 h | 24 h |
Late load materials/shel | 300 ml | 250 ml | 250 ml | 250 ml |
Muti-pipeline | / | / | 8 | 8 |
Φ22mm Bottle | 260 | 165 | 260 | 165 |
Φ16mm Bottle | 480 | 285 | 480 | 285 |
Φ12mm Bottle | 920 | 560 | 920 | 560 |
Exterior(W*D*H mm) |
| 580*500*720+430 drum height | ||
