BNC male plug crimp type connector for RG174 RG316 RG178 LMR100 coaxial cable (62509548271)

Share on:


Price:0,45 $ - 0,75 $
Price in USD:Details

Quantity:


Product Overview

Description


BNC male plug crimp type connector for RG174 RG316 RG178 LMR100 coaxial cableQQ20191030160547


Overview


RF coaxial adaptor has high reliability, strong vibration resistance, mechanical and electrical characteristics of excellent performance. It is widely used in vibration and environment under the condition of radio equipment and instrument , ground launch system, and it can join all kinds of coaxial cables.


 Application


Electrical Characteristics













































Name

BNC connector



Impedance



50Ω/75Ω



Frequency range



0~14GHz



Working Voltage



2700V max



Withstand Voltage



4000V rms



VSWR


Straight


Rigth Angle






≤ 1.2


≤ 1.3



Contact resistance


-center contact


-outer contact






≤5mΩ


≤5mΩ



Insulation resistance



≥10000MΩ



Temperature range



-55°C~+155°C



Durability(matings)



 >500





Construction




































Piece part



Material



plating



Body



Brass



Nickel plated



Center conductor



Brass or Phosphor Bronze



Gold or silver plated



Crimping suite



Copper alloy



Nickel plated



O-ring sealing



6146 silastic




Insulator



PTFE
