| Model | DW50NC |
| Maximum bending pipe diameter x thickness | Φ50mm×3mm |
| Maximum bending radius | R350 |
| Minimum bending radius | According to the pipediameter |
| The largest bending angle | 190° |
| Motor power | 5.5kw |
| Number of elbow bending pipe | 16 |
| Number of storable parts | 16x16 |
| Standard core length | 2200 |
| Control System | NC control |
| Hydraulic system control | The electromagnetic valve |
| Max hydraulic pressure | 12MPa |
| Weight of machine | 1220Kg |
| Measurement size of machine | 3000×700×1030mm |
| Fuel tank capacity | 150 |
FEATURES
-This machine adopts NC control ,hydraulic drive,with a variety of different prefabricated angle
-Chinese &English subtitles display ,Human-machine dialogue types operation ,can choose manual,semi-automatic coperation mode
-Mobile foot switch with both start and stop functions
-With a large-capacity cooling system,effectively control of operating temperature
-The whole machine has the characteristics of convenient operation stable performance,high work efficiency,high safety factor,etc. It is the ideal equipment for the tube processing industry
