2020 Newest 3KW Hybrid Mppt Solar Inverter, Supports No Battery Working And WIFI Remote Control

Product Overview

Description

2020 Newest 3KW Hybrid Mppt Solar Inverter, Supports No Battery Working And WIFI Remote Control

Features



1. With MPPT solar charger controller built inside. 2. Wide PV input range (Up to 600Vdc), can work without battery during the day time. 3. Various communication such as WIFI/RS485/RS232 optional. 4. Smart and intelligent pure sine wave, high frequency technology,wall amounted design,light weighted and easy to operate
5. Selectable charging current based on applications
6. Configurable AC/Solar input priority via LCD setting
7. Compitable with (LI Ion, LiFePo4 and ect.), batteries with BMS system and battery equalization 8. Parallel operation with up to 9 units for 5KW
9. Auto restart while AC is recovering, auto charge and switch, unattended operation 10. Smart battery charger and management for optimized battery performance
12. High Efficient DC-To-AC Conversion.Minimizing Energy Loss and self power consumption 13. All around protection functions: Overload/short circuit protection/high voltage/low battery voltage/high temerature,etc.





Specification

SUNPOLO Smart pure sine wave Solar inverter +MPPT solar charger+AC charger inside, high frequency technology, 100% power, Configurable AC/Solar input priority via LCD setting.Wall mounted design. AC Output: 230V. Support wifi and computer monitor withRS232 interface.Max PV input: 500Vdc.  Can work without battery at daytime.







SUNPOLO TECHNICAL PARAMETER
Rated Power	SUNPOLO 3KW	SUNPOLO 5KW
INPUT
Voltage	230VAC
Voltage Range	176-280 VAC at 100% load
	110-280 VAC at 50% load
Frequency Range	50Hz/60Hz(Auto sensing)
OUTPUT
AC Voltage Regulation(Batt.Mode)	230VAC±3%
Surge Power	6400VA for 5 sec	10400VA for 5 sec
Efficiency(Peak)	>95% ( Rated R load, battery full charged
Transfer Time	10ms typical (UPS)
	20ms typical (Appliances)
Waveform	Pure sine wave
BATTERY
Battery Voltage	24 VDC	48 VDC
Floating Charge Voltage	27 VDC	54 VDC
Overcharge Protection	32 VDC	64 VDC
SOLAR CHARGER & AC CHARGER
Solar Charger Type	MPPT
Maximum PV Array Open Circuit Voltage	500VDC
Maximum PV Array Power	4000W	5000W
MPP Range@ Operating Voltage	120-450VDC	120-450VDC
Maxmum Solar Charge Current	80A	80A
Maximum AC Charge Current	60A
PHYSICAL
Dimension,D X W X H (mm)	303*471*146/530*377*217
Net Weight(kgs)	11.5	12.2
Communication Interface	Removable OTG USB/RS232/RS458/BLE/Dry-contact,BMS interface,
OPERATING ENVIRONMENT
Humidity	5% to 95% Relative Humidity(Non-condensing)
Operating Temperature	-10℃ to 50℃
Storage Temperature	-15℃ to 60℃
