Price:RUB 23,597.37 - RUB 62,926.32

Quantity:


Product Overview

Description

Product Description



Characteristics:

1.High-quality stainless steel or cold rolling steel inner chamber treated by anti-corrosion technology ensures longevity of the product.
2.Micro-compute single chip temperature controller with function of timing and over-temperature protection.
3.High-brightness digital tube display; visual and precise and intuitively with outstanding performance; light touch key for parameters setting.
4.Tightness of door is adjustable; double-layer tempered glass anti-bullet door with high permissibility; silicon rubber seal provides a high vacuum degree.
5.Storage, heating, experiment and drying process are all carried out in a non-oxygen environment filled with inert gases to prevent oxidation.
6.Optional air inflating port for insert gas replenishing.122.jpg

Specifications



  Model  DZ-1AⅡ  DZ-2AⅡ  DZ-3AⅡ
  DZ-1BCⅡ  DZ-2BCⅡ  DZ-3BCⅡ
  Heating mode  Four walls heat conduction and decompression
  Function  Temp.
  Range		  RT+10-250℃
  Useful vacuum
  degree Range		  <133Pa
  Temp.
  Resolution Ratio		  0.1℃
  Temp. motion  ±1℃
  Heating-up
  time		  80min  100min  120min
  Structure  Inner Chamber  BC model: High quality hairline stainless steel sheet;
  A model: Anticorrosion treatment of high strength
  galvanized sheet
  Outer Shell  Cold rolling steel electrostatic spraying exterior
  Insulation layer  Aluminum silicate fiber
  Heater  Stainless steel electric heating tube
  Observation
  window		  Bullet proof glass, acrylic exterior protection
  Vacuum meter  Pointer type, accuracy class 2.5
  Nozzle diameter  10mm
  Power rating  0.8kW  1.4kW  2.0kW
  Controller  Temp. control
  mode		  Two temperature section PID intelligent
  Temp. setting
  mode		  Touch button setting
  Temp. display
  mode		  Measuring temperature: display on the four digital tubes
  upper row ; setting temperature: display on the
  lower row
  Timer  0-9999min(with timing wait function)
  Operation function  Fixed temperature operation, timing function, auto stop
  Additional function  Sensor deviation correction, temperature overshoot
  self-tuning, internal parameter locking,
  power-off parameter memory
  Sensor  pt100
  Safety device  Over temperature sound-light alarm
  Specification  Inner Chamber
  size(W*L*H)
  (mm)		  300*300*270  415*370*340  450*450*450
  Exterior size
  (W*L*H)(mm)		  480*480*606  560*540*680  640*590*780
  Packing size
  (W*L*H)(mm)		  590*550*750  704*620*814  739*700*889
  Volume  24L  52L  91L
  Number of shelf  2
  Load per rack  15kg
  Shelf space  100mm  140mm  185mm
  (50/60HZ)
  Current rating		  AC220V/3.6A  AC220V/6.3A  AC220V/9.1A
  NW/GW (kg)  42/52  67/92  82/105
  Accessory  Shelf  2
  Shelf frame  4
  optional accessories  Silica gel connecting pipe, vacuum pump
