Used for all kinds of tablet for remove dust .Automatic tablet polish on all sides,and high quality dedusting with out damage to the tablet itself .
SPECIFICATIONS FOR JF-200C UPHIL DEDUSTER MACHINE
1
Granule size
mm
Φ3-Φ25
2
Capacity
Pcs/H
1000000
3
Removal distance
m
7.5
4
Power
w
150
5
Vacuum pump
Mpa
0.05
6
Compressed air
m3/min
0.1
7
Oversize of machine
Mm
500*550*1400
8
Weight of machine
Kg
80
Main Features
operation is very easy Protect materials from harm Long dedusting path ,automatic tablet polish on all sides
High quality dedusting with out damage to the tablet itself
Delivering device for any shape of tablet
Meet GMP standard
Certifications
Detailed Images
Machine Parts
Name: Inlet outlet trachea
Material: 304/316L Stainless steel
Original: Jianfeng Machinery
For this machine many are equipped with tablet press machine ,we can order to the press and then require this machine.we have two types one is left inside and right outside another is opposite
Main Features
Name:Vibration plate Material: 304/316L Function: Parameters Storage tablet/pills,strong volume,vibration plate to separate tablet/ dust,polish on all side of machines
Machine Parts
Name: Dust box ,control panel Material: 304 Stainless steel Original: Jianfeng Machiney Collect dust and under the box can connect with vaccum,panel we can turn on/off,adjust the speed
Machine Parts
Name:Adjustable support feet Material:304 Stainless steel Original: Jianfeng Machiney Supports the entire equipment ,equipped with a deduster machine that is about the same height as a tablet press outlet
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Packing & Delivery
Packaging
Size
550(L) * 650 (W) *1550(D)
Weight
95 KG
Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
