specification | unit | LGJ-30FD |
shelf area | m2 | 0.4 |
shelf temp.range | ℃ | -50℃~+70℃ |
input capacity | L | 4(material thickness 10mm) |
shelf number | layers | 4 |
shelf size | mm | 300×340 |
shelf spacing | mm | 50 |
ice condensing capacity | Kg/24H | 8 |
condensr temp.(no loading ) | ℃ | ≤-75℃ |
cooling method | - | air cooling |
defrosting | - | Natural defrosting |
final vacuum (no loading ) | Pa | ≤5pa |
installation rate | Kw | 2.7 |
hexternal dimension (L*W*H) | mm | 890×660×1210 |
total weight | KG | 280 |
* Integral design, connect to public facilities to use
* Embedded 7-inch high-resolution color LCD touch screen
* A new generation of Lyo-Control plus PC control system
* Support multi-language, temperature, pressure and other units to change display
* Intelligent data export, alarm information reminder, maintenance information prompt, permission password login
* Products meet cGMP and other related requirements
* Has a high price/performance ratio




1.Suitable for freeze-drying bulk(liquid, paste or solidity) conventional materials.
2.It is often used in the laboratory or at home.
3.Can make fruit, dried flowers, serum, medicine and so on.

Beijing Songyuan Huaxing Technology Development Co., Ltd. was founded in 2000 and specializes in the R&D, production and sales of vacuum freeze-drying products. With the vacuum freeze dryer as the core product, forming different scales and different applications of three series of products as well as targeted solution for scientific research experiment, medical, and food industry. We are well-known on providing the vacuum freeze-drying equipment and targeted solution in China.
We are one of the first domestic enterprises engaged in vacuum freeze-drying technology and safety production standardization of Beijing industrial enterprises. Our head office is in Beijing. We have the branches and special maintenance stations in Shanghai, Guangdong, Wuhan, Xian, and Chengdu. Our products are exported to the United States, Russia, South Korea, Japan, Singapore, Malaysia, Canada and other countries.





* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* One year warranty.
