12v dc electric motor micro motor small motor for hair dryer
Product Description
12v dc electric motor micro motor small motor for hair dryer
Kinmore--Smart power solutions provider since 1998 21 years of' motor design and production experience. 90 million-piece annual capacity. Auto motors are almost entirely produced on automated lines Facilities certified to IAFT16949:2016, ISO 9001:2008 and ISO 14001:2004 Advanced equipment from Sodick, Hexagon, Mitutoyo, Magtrol, and Votsch 10% of sales revenue invested in R&D and automatic equipment every year Reject rate: auto motors < 30PPM;general motors is < 500PPM
MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
OPERATING
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
TORQUE
CURRENT
RANGE
V
r/min
A
r/min
A
mNm
g.cm
W
mNm
g.cm
A
RS-390SH
20156R
6.0-12.0
12
5000
0.08
4243
0.33
6.07
61.9
2.72
42.2
430
2.22
2975
6.0-12.0
12
12000
0.29
10165
0.33
5.75
58.6
1.31
80.4
820
8.9
RS-395SH
15130
6.0-12.0
12
3650
0.66
2949
0.25
5.83
59.5
1.8
30.4
310
1.06
15100R
6.0-24.0
24
10300
0.07
8893
0.38
7.09
72.3
6.68
54.9
560
2.66
Customized items: DC motor, gearbox motor, vibration motor, automotive motor. Accessories offered like encoder, gear,worm, wire, connector. Ball bearing or Oil-impregnated bearing. Shaft configuration(multi-knurls,D-cut shape, four-knurls etc). Metal end cap or plastic end cap. Precious metal brush/ carbon brush. Technical data.
12v dc electric motor micro motor small motor for hair dryer
Samples are customized based on different requirements
Application
Automobile: electric scooters,electric parking brake, steering wheel regulator, car seat, review mirror,electric throttle control system, car lock, odometer,headlight, windshield wiper, trunk opener,electric vacuum pump, electric lumbar support, air conditioner for car.
Personal care: hair dryer,massager, hair clipper, adult toy, electric shaver, electronic toothbrush, etc.
Precision equipment: camera, printer, scanner, medical machine etc.
Home appliance: vacuum cleaner, air fresheners, automatic floor cleaner, coffee machines, blender, juicer, mixer, slow cooker, electric iron, electric cooker,eggbeater, toaster, computer tables, electric mahjong tables, motorized curtain, automatic blinds, robot vacuum cleaner, electric lock, door lock, electric fragrance lamp,smart toilet,electronic curtain, dishwasher,intelligent toilet etc. Industry: ATM,power tools, electric screwdriver, electric drill, water meter,water pump, air pump, submersible pump. Robots: robotic arms, robot, etc.
More DC motors
Kinmore R&D:
In order to ensure that the new DC motor and gear motor can be delivered to customers with maximum satisfaction,Kinmore sales engineers should get and understand completely customers’ products original requirements which include: A. DC motor/ Gear motor dimensions and connection installation dimensions. B.Electrical performance data: Vol. Working Speed, Current, and torque. Stall Current and Torque. Work duty, working environment conditions, Noise, Life expectancy, etc. C. The markets regulation and laws (option) i.e., RoHS, etc D. Other requirements,i.e. cost targets.
Company Information
12v dc electric motor micro motor small motor for hair dryer
12v dc electric motor micro motor small motor for hair dryer
FAQ
Q:1.What kind of motors you can provide?
A: For now, we mainly provide permanent magnet brushed dc motors (including vibration motors, low voltage dc motors and high voltage dc motors) with diameter range in 6~80mm and also Dia10~80mm size gear motors.
Q:2. Can you send me a price list?
A: For all of our motors, they are customized based on different requirements like lifetime, noise, voltage, and shaft etc. The price also varies according to annual quantity. So it's really difficult for us to provide a price list. If you can share your detailed requirements and annual quantity, we'll see what offer we can provide.
Q:3. What's the lead time for regular order?
A: For orders, the standard lead time is 35-40 days and this time can be shorter or longer based on different model, period and quantity.
Q:4. Is it possible for you to develop new motors if we can provide tooling cost?
A: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we'll make our evaluation to see if we can arrange or not.
Q:5. Can I get some samples?
A: It depends. If only a few samples for personal use or replacement, I am afraid it'll be difficult for us to provide because all of our motors are custom made and no stock available if there is no further needs. If just sample testing before the official order and our MOQ, price and other terms are acceptable, we'd love to provide samples.
How to contact us
if you have any questions,plz send an inquiry to us.
We will reply you as soon as possible. Thank you so much!
12v dc electric motor micro motor small motor for hair dryer
