Product Description
INTRODUCTION
This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger tooffer
uninterruptible power support with portable size. lts comprehensive LCD display offers user-configurableand easy-accessible button operation such as battery charging current，AC/solar charger priority , and acceptable input voltage based on different applications.
uninterruptible power support with portable size. lts comprehensive LCD display offers user-configurableand easy-accessible button operation such as battery charging current，AC/solar charger priority , and acceptable input voltage based on different applications.
FEATURES
* Pure sine wave inverter* Configurable input voltage range for home appliances and personal computers via LCD setting
* Configurable battery charging current based on applications via LCD setting
* Configurable AC/Solar Charger priority via LCD setting
* Compatible to mains voltage or generator power
* Auto restart while AC is recovering Overload/ Over temperature/ short circuit protection
* Smart battery charger design for optimized battery performance
* Cold start function
* Configurable battery charging current based on applications via LCD setting
* Configurable AC/Solar Charger priority via LCD setting
* Compatible to mains voltage or generator power
* Auto restart while AC is recovering Overload/ Over temperature/ short circuit protection
* Smart battery charger design for optimized battery performance
* Cold start function
FUNCTIONS
1.LCD display
2.Status indicator
3.Charging indicator
4.Fault indicator
5.Touch Function buttons
6.Power on/off switch
7.AC input
8.Main output
9.Second output
10.Pv1 and Pv2 input
11.Anti dust kit
12.RS-232/WIFI/Remove LCD communication port
13.Battery input
2.Status indicator
3.Charging indicator
4.Fault indicator
5.Touch Function buttons
6.Power on/off switch
7.AC input
8.Main output
9.Second output
10.Pv1 and Pv2 input
11.Anti dust kit
12.RS-232/WIFI/Remove LCD communication port
13.Battery input
Basic System Architecture
The following illustration shows basic application for this inverter/charger. It also includes following devices tohave a complete running system:
Generator or Utility
PV modules
Consult with your system integrator for other possible system architectures depending on your requirements.This inverter can power
all kinds of appliances
in home or office environment, including motor-type appliancessuch as tube light, fan, refrigerator and air conditioner.
item | |||
Place of Origin | China | ||
Guangdong | |||
Brand Name | PowMr | ||
Product name | hybrid solar inverter | ||
Model Number | HVM8.2M | ||
DESCEPITION | POW-HVM8.2M | ||
Inverter type | MPPT | ||
Type | DC/DC Converters, DC/AC Inverters | ||
Size | 579*390*130 | ||
Weight | 14.2 | ||
Model Number | POW-HVM8.2M | POW-HVM10.2M | |
Maximum PV Input Power | 6200W | 6500W | |
Rated Output Power | 8200W/8200VA | 10200W/10200VA | |
Maximum Solar Charging Current | 160A | 180A | |
GRID-TIE OPERATION | |||
PV Input(DC) | |||
Nominal DC Voltage/Maximum DC Voltage | 360VDC/500VDC | ||
Start-up Voltage/Initial Feeding Voltage | 90VDC/120VDC | ||
MPPT Voltage Range | 90VDC~450VDC | ||
Number Of MPPT Trachers/Maximum Input Current | 1/27A | ||
GRID OUTPUT(AC) | |||
Nominal Output Voltage | 200/230/240VAC | ||
Output Voltage Range | 195.5~253VAC | ||
Nominal Output Current | 35.6A | 44.3A | |
Power Factor | >0.99 | ||
EFFICIENCY | |||
Maximum Conversion Efficiency(DC/AC) | 98% | ||
TWO LOAD OUTPUT POWER(V2.0) | |||
Full Load | 8200W | 10200W | |
Maximum Main Load | 8200W | 8200W | |
Main Load Return Voltage | 2733W | 3400W | |
Main Load Cut Off Voltage | 44VDC | 44VDC | |
Main Load Return Voltage | 48VDC | 48VDC | |
OFF-GRID OPERATION | |||
AC INPUT | |||
AC Start-up Voltage/Auto Restart Voltage | 120-140VAC / 180VAC | ||
Acceptable Input Voltage Range | 90-280VAC or 170-280VAC | ||
Maximum AC Input Current | 40A | 50A | |
Nominal Operating Frequency | 50/60Hz | ||
Surge Power | 16400W | 20400W | |
PV INPUT(DC) | |||
Maximum DC Voltage | 500VDC | ||
MPPT Voltage Range | 90VDC~450VDC | ||
Number of MPPT Trackers/Maximum Input Curren | 1/27A | ||
BATTERY MODE OUTPUT(AC) | |||
Nominal Output Voltage | 48VDC | 48VDC | |
Output Wavefrom | Pure sine wave | ||
Efficiency(DC to AC) | 94% | ||
BATTERY & CHARGER | |||
Maximum Solar Charging Current | 160A | 180A | |
Maximum AC Charging Current | 140A | 160A | |
company profile
Our company has been engaged in solar charge controller field for 8 years, we had very good cooperation with many large famous manufacturers during this period .We sell authorized EPever and SMK products on the online shopping website such as Amazon, eBay , Aliexpress ,Lazada and also provide OEM, ODM for many customers from all over the world, and we also have our own PowMr,Y-SOLAR trademark .
FAQ
1. who are we?
We are based in Guangdong, China, start from 2014,sell to North America(20.00%),Africa(15.00%),Southeast Asia(15.00%),Western Europe(15.00%),South America(15.00%),Domestic Market(10.00%),Mid East(5.00%),Eastern Europe(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Solar Charger Controller,Solar Inverter,Solar Water Pump,MC4 Tool,MC4 Connector
4. why should you buy from us not from other suppliers?
Our company has been engaged in solar charge controller field 8 years, we had very good cooperation with many large famous manufacturers during this period .We also have our own Temank ,PowMr,Y-SOLAR trademark .
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,DDP,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Japanese,German
We are based in Guangdong, China, start from 2014,sell to North America(20.00%),Africa(15.00%),Southeast Asia(15.00%),Western Europe(15.00%),South America(15.00%),Domestic Market(10.00%),Mid East(5.00%),Eastern Europe(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Solar Charger Controller,Solar Inverter,Solar Water Pump,MC4 Tool,MC4 Connector
4. why should you buy from us not from other suppliers?
Our company has been engaged in solar charge controller field 8 years, we had very good cooperation with many large famous manufacturers during this period .We also have our own Temank ,PowMr,Y-SOLAR trademark .
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,DDP,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Japanese,German
