Dxtech четыре функции материала намотки лазерной резки с 3000*1500 мм стол
661 267,80 ₽ - 2 204 115,79 ₽
CA F 1325 японский двигатель Serove обработка листового металла строительный станок для лазерной резки волокна
- Категория: >>>
- Поставщик: Jinan Camel CNC Machinery Co. Ltd.
Сохранить в закладки 1601227503858:
Описание и отзывы
Характеристики
Camel CNC Sheet metal processing Online Support Good Quality Best Price Cutting Metal Materials laser cutting machine fiber
1 | Working voltage Three phase,380V,50/60HZ |
2 | Working size 1500*3000mm |
3 | Taiwan HIWIN Linear Guide Rail |
4 | X,Y Axis Japan FUJI 1000W Servo motor and Driver, Z axis 400w FUJI Servo motor with brake and driver, total 4 sets. |
5 | High speed TAIWAN YYC rack gear Transmission |
6 | Original CypCut control System |
7 | Raytool Adjust Laser head |
8 | MAX 1500W Fiber laser generator |
9 | Japan Shimpo reducer |
10 | HL1500 water chiller |
Model | CA-F1530 |
Working area | 1500x3000mm |
Laser Power | 1500W |
Laser Wavelength | 1064nm |
Application Materials | Metal |
Max. Cutting Thickness | SS:6-8MM,MS:12-16MM,Aluminum:3mm |
Gross Power | 11KW |
Positioning Accuracy | ±0.03mm/m |
Reposition Accuracy | ±0.02mm |
X/Y-axis Maximum Simultaneous Positioning Speed | 140m/min |
U-axis max.moving speed | 80m/min |
Cooling Model | Water cooling |
Rotary system | Optional |
Servo Motor
Use top brand HCFA, etc. High power motor system on X, Y, Z axis. High precision gives better cutting effect, high speed gives faster cutting speed.
Industrial Heavy Machine Bed
A solid bed has high stability, the use of cast iron as a raw material keeps the precision of the machine tool for a long time.
Au3tech A230E Laser Head
Higher cutting quality and efficiency with cutting speed being up to 60m/min with perfect cutting edge.
RECI Fiber Laser Generator
has high and stable function and lifespan which is over 100000 hours.
CWFL1500 Water Chiller
Water chiller high capacity provides stability during long-term operation.
Au3tech SC2000 Controller
Industry CPU + Wireless handheld
Easy operation, Big screen.
Easy operation, Big screen.
Q1: How to choose a suitable machine?
You can tell us the working piece material, size, and the request of machine function. We can recommend
the most suitable machine according to our experience.
You can tell us the working piece material, size, and the request of machine function. We can recommend
the most suitable machine according to our experience.
Q2:This is the first time i buy the machine, is it easy to operate?
We can provide the operation manual or video for guiding. If it is hard for you learning, we can also help
you by “Team viewer" online, with telephone or Skype explain.
We can provide the operation manual or video for guiding. If it is hard for you learning, we can also help
you by “Team viewer" online, with telephone or Skype explain.
Q3: Can you customize the machine for me?
Yes, we provide customized solution, but considering the cost, we will recommend the standard
configuration to you first.
Yes, we provide customized solution, but considering the cost, we will recommend the standard
configuration to you first.
Q4:What is the guarantee? In case the machine break down?
The machine has 2 year guarantee, fail parts will be replaced for free if the machine under "normal
operation".
The machine has 2 year guarantee, fail parts will be replaced for free if the machine under "normal
operation".
Q5:How about the documents after shipment?
We will send all the documents by air after shipment. Including packing list, commercial invoice, B/L, and
other certificates required by clients.
We will send all the documents by air after shipment. Including packing list, commercial invoice, B/L, and
other certificates required by clients.
Q6: Delivery time?
For standard machine, it would be 7-10 working days; for non-standard machine, it would be20-30working
days.
For standard machine, it would be 7-10 working days; for non-standard machine, it would be20-30working
days.
Q7:How is the payment?
Normally we accept T/ or L/C, if you like other terms, tell us in advance.
Normally we accept T/ or L/C, if you like other terms, tell us in advance.
Q8: Do you arrange the shipment for me?
For FOB or CIF price, we will arrange shipment for you, for EXW price, you should arrange the shipment by
yourself.
For FOB or CIF price, we will arrange shipment for you, for EXW price, you should arrange the shipment by
yourself.
Q9:How is the packing?
Step1: water proof wrapping film with foam protection in each corner.
Step2: Solid seaworthy wood box package with steel belt.
Step3: Save space as much as possible for container loading.
Step1: water proof wrapping film with foam protection in each corner.
Step2: Solid seaworthy wood box package with steel belt.
Step3: Save space as much as possible for container loading.
