S5731 L8T2ST RUA 98011778 управляемый коммутатор poe с портами 8*10/100/1000BASE T порт 1 * GE SFP 1*10/100/1000BASE T

S5731 L8T2ST RUA 98011778 управляемый коммутатор poe с портами 810/100/1000BASE T порт 1 GE SFP 1*10/100/1000BASE T

Категория: >>>
Поставщик: Chongqing Yujia Technology Co. Ltd.Chongqing Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Product Description

S5731-L8T2ST-RUA (8*10/100/1000BASE-T ports, 1*GE SFP port, 1*10/100/1000BASE-T port, AC power, power adapter)

Item	Details
Part Number	98011778
Model	S5731-L8T2ST-RUA
Description	S5731-L8T2ST-RUA (810/100/1000BASE-T ports, 1GE SFP port, 1*10/100/1000BASE-T port, AC power, power adapter)

Details Images

Specification

Wide [mm]	210.0 mm
Depth [mm]	130.0 mm
Height [mm]	27.0 mm
Chassis height [U]	0.61
Weight with packaging [kg(lb)]	1.14 (2.51)
Weight without packaging [kg(lb)]	0.84 (1.85)
Typical power consumption [W]	7.73 W (device) 7.98 W (device + power adapter)
Maximum power consumption [W]	7.86 W (device) 8.11 W (device + power adapter)
Typical heat dissipation [BTU/hour]	26.38 (device) 27.23 (device + power adapter)
Maximum heat dissipation [BTU/hour]	26.82 (device) 27.67 (device +power adapter)
Heat dissipation mode	Natural heat dissipation
Power supply mode	Power adapter
Rated input voltage [V]	Power adapter input: 100–240 V AC; 50/60 Hz Power adapter output: 12 V DC
Input voltage range [V]	Power adapter input: 90–290 V AC; 47–63 Hz
Maximum input current [A]	1 A
Number of card slots	0
Number of power slots	0
Memory	--
Flash memory	--
Redundant power supply	Not supported
Types of fans	None
Noise at normal temperature (acoustic pressure) [dB(A)]	Noise-free (no fans): < 20
Noise at normal temperature (acoustic power) [dB(A)]	Noise-free (no fans): < 30
Airflow direction	-
Long-term operating temperature [°C(°F)]	-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Storage temperature [°C(°F)]	–40°C to +70°C (–40°F to +158°F)
Restriction on the operating temperature variation rate	When the altitude is 1800-5000 m (5905.44-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (721.78 ft.). The device cannot start when the temperature is lower than 0°C (32°F). The operating temperature of a device ranges from -5°C to +45°C (23°F to 113°F)) when the device uses the following optical modules: - GE optical modules with a transmission distance of less than or equal to 10 km
Long-term operating relative humidity [RH]	5% RH to 95% RH (non-condensing)
Long-term operating altitude [m(ft.)]	0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
MTBF [year]	84.79
MTTR [hour]	2
Availability	>0.99999
Maximum number of physical ports on the entire device	10
Maximum number of 100GE ports	0
Maximum number of 40GE ports	0
Maximum number of 25GE ports	0
Maximum number of 10GE ports	0
Maximum number of GE ports	10
Maximum number of FE ports	9
1000M electrical interface	8
1000M optical interface	1
USB	Not supported
Console port	Not supported
Eth Management port	Not supported
Service port surge protection	Common mode: ±6 kV
Power supply surge protection	Power adapter: ±6 kV in differential mode and ±6 kV in common mode
RPS input	Not supported
PoE	Not supported
