Высококлассная сушилка с флюидированным покрытием для кипячения фармацевтической промышленности
9 700,00 $
Модель XF горизонтальная сушилка для жидкости с поливинилхлоридной смолой
- Категория: Оборудование для сушки в кипящем слое >>>
- Поставщик: Changzhou Kodi Machinery Co. Ltd.
Сохранить в закладки 60339835523:
Описание и отзывы
Характеристики
KODI XF Model PVC Resin Horizontal Fluid Bed Dryer Boiling Dryer
1. PVC Resin fluid bed drying machine / PVC Resin horizontal fluid bed dryer / PVC Resin boiling dryer
2. Continoud drying equipment
3. Fluidization bed
4. Good quality
Product Description
What is PVC Resin
Polyvinyl chloride, more correctly but unusually poly(vinyl chloride), commonly abbreviated PVC, is the third-most widely produced synthetic plastic polymer, after polyethylene andpolypropylene.
PVC comes in two basic forms: rigid (sometimes abbreviated as RPVC) and flexible. The rigid form of PVC is used in construction for pipe and in profile applications such as doors and windows. It is also used for bottles, other non-food packaging, and cards (such as bank or membership cards). It can be made softer and more flexible by the addition of plasticizers, the most widely used being phthalates. In this form, it is also used in plumbing, electrical cable insulation, imitation leather, signage, inflatable products, and many applications where it replaces rubber.
Pure poly(vinyl chloride) is a white, brittle solid. It is insoluble in alcohol but slightly soluble in tetrahydrofuran.
XF Horizontal PVC Resin Horizontal Fluid Bed Dryer Descripiton
PVC Resin horizontal fluid bed dryer is also called fluidization bed. Through operation and improvement about twenty years, it has play an active part in fields of pharmaceutical, chemical, PVC Resin, grain and so on. It consists of air filter, fluidizing bed, cyclone separator, dust remover of bag, high-speed centrifuge and fan, operation table and so on. Because of the difference of property from raw material, it is necessary to equip dust remover in accordance with practical needs. It may select cyclone separator and dust remover at the same time or one of them. In general speaking, cyclone separator can be selected if the raw material is large and the dust remover of bag may be selected if the raw material is light. Moreover, there is air feeding device for your selection.
XF PVC Resin Fluid Bed Drying Machine Applications
It has widely applied in the fields of pharmaceutical, chemicals, powder and granular materials such as bulk Pharmaceuticals, granular patent medicines, preparations, feed, plastic resin etc. The granular diameter shall be within the range from 0.1 to 6mm and the best is 0.5 to 3mm.
Working Principle of Horizontal PVC Resin Boiling Dryer
The clean and hot air enters into fluidization bed through distributor of valve plate. The wet material fed from feeder will be formed a fluidization state by hot air (jumping within the bed like boiling water), so it is called fluidizing dryer(or machine).Because of the large contacting area between hot air and materials, the drying time is short. The air enters from one end of bed, through" boiling" several minutes and then comes out automatically from the other end.
XF PVC Resin Horizontal Fluid Bed Dryer Technical Parameters
Type/ | bed area | drying capacity(kgH2O/h) | power of fan(kw) | inlet air temperature | material temperature | occupied area(m2) | L×W×H(M) |
XF0.25-1 | 0.25 | 10-15 | 5.5 | 120-140 | 40-60 | 18 | 1×0.6×3.35 |
XF0.25-2 | 0.5 | 20-25 | 7.5 | 120-140 | 40-60 | 25 | 2×0.6×3.35 |
XF0.25-3 | 1.0 | 30-45 | 15 | 120-140 | 40-60 | 35 | 4×0.6×3.35 |
XF0.25-6 | 1.5 | 52-75 | 22 | 120-140 | 40-60 | 40 | 6×0.6×3.35 |
XF0.3-2 | 0.6 | -30 | 7.5 | 120-140 | 40-60 | 25 | 2×0.7×3 |
XF0.3-4 | 1.2 | 42-60 | 18.5 | 120-140 | 40-60 | 38 | 4×0.7×3.4 |
XF0.3-6 | 1.8 | 63-90 | 30 | 120-140 | 40-60 | 45 | 6×0.7×3.4 |
XF0.3-8 | 2.4 | 84-120 | 37 | 120-140 | 40-60 | 56 | 8×0.7×3.4 |
XF0.3-10 | 3.0 | 105-150 | 18 | 120-140 | 40-60 | 70 | 10×0.7×3.4 |
XF0.4-4 | 1.6 | 56-80 | 30 | 120-140 | 40-60 | 18 | 4×1×3.58 |
XF0.4-6 | 2.4 | 84-120 | 37 | 120-140 | 40-60 | 56 | 6×1×3.58 |
Successful Experience Overseas By KODI XF Horizontal PVC Resin Fluid Bed Drying Machine
Packaging & Shipping
Company Information
Why Choose KODI
International high quality certification product chain
Manufacturer, more reasonable price
Solid technical support and after-sales service
Uphold the principle of “Customer Supreme”( Balance payment after equipments run normally)
Exports to more than 20 countries and regions, good customers feedback
One-stop service, customized exclusive project feasibility report
Changzhou KODI Machinery Co., Ltd. located in the birthplace of China drying equipment----Zhenglu Industrial Park, Changzhou City, Jiangsu Province which is 150km away from Shanghai city, with a comfortable environment and convenient transportation access.
KODI company is a professional manufacture of drying machine, which include Seaweed processing machine, Seaweed drying machine (Cottonii to carrageenan, Agar agar ), Spray dryer, PVC Resin fluid bed drying machine / PVC Resin horizontal fluid bed dryer / PVC Resin boiling dryer, Flavor spray dryer (Cocoa, Maltdextrin,Gum Acacia), Lab Spray dryer, Vibrating Fluid bed dryer, Rice Paddy Dryer Machine, Gelatin processing machinery, Gelatin drying machine (Hide and bone),Gelatin production line. we also deal in high-quality fermentation tank, Bright tank , Extraction tank, concentration tank , evaporator and etc.
We have implemented a strict and complete quality control system, which ensures that each product can meet quality requirements of customers. Besides, all of our products have been strictly inspected before shipment. Our products conform to international standards, such as CE, SGS.
KODI company also has a lot of top talent which have more than 15years of work experience, include research, design, manufacture and after sale service. Our products sell to all of the world (such as Australia, Malaysia, Indonesia, Vietnam, Philippines, Korea, Brazil, Chile, Peru, Argentina, Russia, Ukraine, South Africa, Cameroon, Sudan, Syria) and also have the good cooperation with the foreign client and vendor.
We are sure that our high quality products and excellent services will be appreciated by the growing list of satisfied customers. Contacting us is the first step to build a long and successful business relationship with us. Welcome!
Our Services
Pre-service
Act as a good adviser and assistant of clients to enable them get rich and generous returns on their investments.
1. Introduce the product to the customer in detail, answer the question raised by customer carefully;
2.Make plans for choice according to the needs and special requirements of users in different sectors;
Sale service
1. Ensure product with high quality and pre-commissioning before delivery;
2. Delivery on time;
3.Provide full set of documents as customer’s requirements.
After-sale service
Provide considerate services to minimize clients’ worries.
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3.Train the first-line operators;
4. Examine the equipment;
5.Take initiative to eliminate the troubles rapidly;
6.Provide technical support;
7.Establish long-term and friendly relationship.
Service commitment
1. Provide clients one-year warranty to make sure the machine work well;
2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;
3.Send every client a preferential quotation.
FAQ
Special Notice:
In order to quota you the right PVC Resin fluid bed drying machine / PVC Resin horizontal fluid bed dryer / PVC Resin boiling dryer with best price, we would like to get the following information include in your inquiry:
-What is the raw material? Material related characteristic? Does it corrosive, strong basicity, or highly acid? Please confirm.
-What is the capacity per hour you need (kg/h)?
-What is the initial moisture and final moisture of finished products you require to get?
-What about the maximum heat temperature of raw material?
-What kind of fuel you use to heat the dryer? Natural gas, electricity, fuel oil or steam?
-Which equipment material do you like prefer? SUS304, SUS316L or Carbon steel?
-Provide us your country’s electricity information, such as phases, voltage, HZ?
-How about dust collect requirements?
-Other special requirements?
Frequently Asked Questions
Q: Can I visit your factory?
A: Yes. Many domestic and international customers visit our factory every year. Our company is near Shanghai.It only takes you about 1 hour to get Changzhou.Or we can visit you in Shanghai.
Q: What’s the quality of your products?
A:Parts of our products come with best quality, and our products passed CE certification, exported to lots countries around the world, such as Australia, Malaysia, Indonesia, Vietnam, Philippines, Korea, Brazil, Argentina, Russia, South Africa, etc. You can rest assured with the quality absolutely.
Q: What to do if the machine has a problem?
A:24 hours timely response of mail and phone calls. If the parts broken belong to non-artificial factors within 12 months, we offer free replacement. If beyond 12 months, customers should bear the freight back and forth and accessories cost.
Q: How long is the warranty of your equipment?
A: Our warranty period is one year generally.
Q: What is your payment term?
A: Our usual payment term is: 30% TT in advance, 70% TT before shipment. Other ways can also be received after we both sides discussion and agreement.
Q: Does your price include freight?
A: Our usual price is based on FOB Shanghai, if you request CIF, please give us your delivery port, and we will give you CIF price.
