Product Overview
Description
Voltage Dip, Interruption Simulators DRP61011TA is designed for for voltage dips, short interruptions immunity test requirements and provide an assessment for the low-voltage grid connection of voltage dips, short interruptions interference. The products are fully compliant with the IEC61000-4-11 standard with intelligent, stable performance, easy operation.
Product characteristic:
LCD display, Intelligent control,stable performance
Programmable design operated by a key setting function
Built-in many user modes, programmable design, Easy to operate
Built-in intelligent coupling/ decoupling network, Testing safety
Built-in the RS232 interface ,Remote operated by the optional control software.
Technical parameters:
Model | DRP61011TA |
Level of voltage dips | 0% ~ 110% |
Dip duration | 1~9999(half cycle) |
Phase | Synchronism 0 °~ 360 °selectable/Asynchronism |
Repetition time | 1~60000 |
Dip interval | 1~9999(half cycle) |
Trigger mode | Automatic ,internal trigger |
EUT power supply capability | AC220V,10A |
Working power supply | AC220V 50/60Hz |
Ambient temperature | 15 °C~35 °C |
Weight | 20kg |
Outline dimensions | 440×430×180 mm |
