Weshine сопротивления заземления тестирования сопротивления Земли Тестер Цифровой тестер сопротивления заземления (1600747340999)

Share on:

Price:680,00 $ - 750,00 $
Price in USD:Details


Product Overview


Product Description

1.Soil resistivity tester supports 2, 3 and 4wire grounding resistance measurement.
2. 4digit large LCD display with white screen backlight, suitable for use in dimly lit places.
3. IP65 protection grade, good waterproof, compact and portable, supports multiple functional tests.
4. Ground resistance measurement range is 0.0030.00kΩ, and soil resistivity is 0.00Ωm900kΩm.
5. Support ground voltage, AC voltage measurement, high accuracy, long-term use.

Item Type: Soil Resistivity Tester
Material: ABS
Model: ETCR3100C
Function: 2, 3 and 4 wires to measure grounding resistance, soil resistivity; grounding voltage, AC voltage measurement
Working Voltage: DC7.4V 2600mAh x1 Rechargeable lithium battery, the battery is fully charged about 8.4V (built-in battery)
Adapter: US Standard AC100-240V
1. Grounding Resistance: 0.00 - 30.00kΩ
2. Soil Resistivity: 0.00Ωm - 900kΩm
3. Grounding Voltage: 0V - 600V
Measurement Method: Precise 4-wire, 3-wire method measurement, simple 2-wire measurement of ground resistance
Measurement: Grounding Resistance: Rated current pole changing method, measuring current 20mA Maximum
Soil Resistivity: Quadrupole Method (Winner Method)
Voltage To Ground: Average Value Rectification (Between P(S)-ES Interface)
Test Frequency: 128Hz/111Hz/105Hz/9Hz (AFC)
Short Circuit Test Current: AC 20mA Maximum
Open Circuit Test Voltage: AC 40V Maximum
Test Voltage Waves: Sine Waves
Electrode Spacing Range: 1m-100m can be set


Brand Name
Product name
Grounding Resistance
0.00 - 30.00kΩ
Soil Resistivity
0.00Ωm - 900kΩm
Grounding Voltage
0V - 600V
Test Frequency
128Hz/111Hz/105Hz/9Hz (AFC)
Short Circuit Test Current
AC 20mA Maximum
Open Circuit Test Voltage
AC 40V Maximum
Test Voltage Waves
Sine Waves
Electrode Spacing Range
1m-100m can be set
Working Temperature and Humidity
-10℃-40℃; below 80%RH
