KFD2 STC5 1.2O Pepperl+Fuchs SMART Transmitter Power Supply
- Category: Other Electrical Instruments >>>
- Supplier: Shenzhen,Minglan,Optoelectronic,Trading,Co.,Limited
Share on:
Product Overview
Description
Product Description
SMART Transmitter Power Supply KFD2-STC5-1.2O
The device supports the following SMART protocols:
• HART
• BRAIN
• Foxboro
1-channel signal conditioner
24 V DC supply (Power Rail)
Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources
Signal splitter (1 input and 2 outputs)
Dual output 0/4 mA ... 20 mA, current sink/current source
Terminals with test points
Up to SIL 3 acc. to IEC 61508
Please note: All product-related documents, such as certificates, declarations of conformity, etc., which were issued prior to the conversion under the name Pepperl+Fuchs GmbH or Pepperl+Fuchs AG, also apply to Pepperl+Fuchs SE.
\t
Signal type\tAnalog input
Safety Integrity Level (SIL)\tSIL 3
Systematic capability (SC)\tSC 3
Connection\tPower Rail or terminals 14+, 15-
Rated voltage\t18 ... 30 V DC
Ripple\twithin the supply tolerance
Power dissipation\t≤ 1 W at maximum load
Power consumption\t≤ 1.7 W at maximum load
\t
Connection side\tfield side
Connection\tterminals 1+, 2-, 3
Input signal\t0/4 ... 20 mA
Open circuit voltage/short-circuit current\tterminals 1+, 3: 23 V / 25 mA
Input resistance\tmax. 265 Ω terminals 2-, 3 , max. 330 Ω terminals 1+, 3
Available voltage\t≥ 16 V at 20 mA ; ≥ 20 V at 4 mA , terminals 1+, 3
Output
Connection side\tcontrol side
Connection\tterminals 7+, 8-, 9-; 10+, 11-, 12- (sink)
terminals 7-, 8+, 9+; 10-, 11+, 12+ (source)
see additional information
Load\t0 ... 600 Ω
Output signal\t0/4 ... 20 mA (overload > 25 mA)
Ripple\tmax. 50 µA eff
External supply (loop)\t2 ... 30 V DC
Transfer characteristics
Deviation\tat 20 °C (68 °F), 0/4 ... 20 mA
≤ ± 10 µA incl. calibration, linearity, hysteresis, loads and supply voltage fluctuations
Influence of ambient temperature\t≤ 0.25 µA/K
Frequency range\tinput in output: bandwidth with 1 mApp signal 0 ... 7.5 kHz (-3 dB)
output in input: band width with 1 Vss signal 0.3 ... 7.5 kHz (-3 dB)
Settling time\t200 µs
Rise time/fall time\t100 µs
Galvanic isolation
Input/Output\tbasic insulation according to IEC 61010-1, rated insulation voltage 300 Veff
Input/power supply\tbasic insulation according to IEC 61010-1, rated insulation voltage 300 Veff
Output/power supply\tfunctional insulation, rated insulation voltage 50 V AC
Output/Output\tfunctional insulation, rated insulation voltage 50 V AC
Display elements\tLED
Labeling\tspace for labeling at the front
Directive conformity
Electromagnetic compatibility\t
Directive 2014/30/EU\tEN 61326-1:2013 (industrial locations)
The device supports the following SMART protocols:
• HART
• BRAIN
• Foxboro
1-channel signal conditioner
24 V DC supply (Power Rail)
Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources
Signal splitter (1 input and 2 outputs)
Dual output 0/4 mA ... 20 mA, current sink/current source
Terminals with test points
Up to SIL 3 acc. to IEC 61508
Please note: All product-related documents, such as certificates, declarations of conformity, etc., which were issued prior to the conversion under the name Pepperl+Fuchs GmbH or Pepperl+Fuchs AG, also apply to Pepperl+Fuchs SE.
\t
Signal type\tAnalog input
Safety Integrity Level (SIL)\tSIL 3
Systematic capability (SC)\tSC 3
Connection\tPower Rail or terminals 14+, 15-
Rated voltage\t18 ... 30 V DC
Ripple\twithin the supply tolerance
Power dissipation\t≤ 1 W at maximum load
Power consumption\t≤ 1.7 W at maximum load
\t
Connection side\tfield side
Connection\tterminals 1+, 2-, 3
Input signal\t0/4 ... 20 mA
Open circuit voltage/short-circuit current\tterminals 1+, 3: 23 V / 25 mA
Input resistance\tmax. 265 Ω terminals 2-, 3 , max. 330 Ω terminals 1+, 3
Available voltage\t≥ 16 V at 20 mA ; ≥ 20 V at 4 mA , terminals 1+, 3
Output
Connection side\tcontrol side
Connection\tterminals 7+, 8-, 9-; 10+, 11-, 12- (sink)
terminals 7-, 8+, 9+; 10-, 11+, 12+ (source)
see additional information
Load\t0 ... 600 Ω
Output signal\t0/4 ... 20 mA (overload > 25 mA)
Ripple\tmax. 50 µA eff
External supply (loop)\t2 ... 30 V DC
Transfer characteristics
Deviation\tat 20 °C (68 °F), 0/4 ... 20 mA
≤ ± 10 µA incl. calibration, linearity, hysteresis, loads and supply voltage fluctuations
Influence of ambient temperature\t≤ 0.25 µA/K
Frequency range\tinput in output: bandwidth with 1 mApp signal 0 ... 7.5 kHz (-3 dB)
output in input: band width with 1 Vss signal 0.3 ... 7.5 kHz (-3 dB)
Settling time\t200 µs
Rise time/fall time\t100 µs
Galvanic isolation
Input/Output\tbasic insulation according to IEC 61010-1, rated insulation voltage 300 Veff
Input/power supply\tbasic insulation according to IEC 61010-1, rated insulation voltage 300 Veff
Output/power supply\tfunctional insulation, rated insulation voltage 50 V AC
Output/Output\tfunctional insulation, rated insulation voltage 50 V AC
Display elements\tLED
Labeling\tspace for labeling at the front
Directive conformity
Electromagnetic compatibility\t
Directive 2014/30/EU\tEN 61326-1:2013 (industrial locations)
Specification
item | value |
Place of Origin | Singapore |
Brand Name | Pepperl+Fuchs |
Model Number | KFD2-STC5-1.2O |
Dimensions | 20*20*10cm |
Weight | 0.5kg |
Signal type | Analog input |
Product type | SMART Transmitter Power Supply |
Model No | KFD2-STC5-1.2O |
Safety Integrity Level (SIL) | SIL 3 |
Input signal | 0/4 ... 20 mA |
Connection side | control side |
Load | 0 ... 600 Ω |
Deviation | at 20 °C (68 °F), 0/4 ... 20 mA |
Operating voltage | 5 ... 25 V |
