Дисковый тормоз для мотоцикла, 17 дюймов, 4500 Вт, 60 В, 72 в, скорость двигателя 120 ярдов, модифицированный мотор для мотоцикла
- Category: Motorcycle Motor >>>
- Supplier: Wuxi,Tonglai,Yuehao,Trading,Co.,Ltd.
Share on:
Product Overview
Description
Motor Type | Brushless Direct Current Motor(BLDC Motor) | |||||
Axle Configuration | 20mm | |||||
Wheel Rim | 17 inch | |||||
Rated Speed | 120km/h | |||||
Voltage | 60V/72V | |||||
Magnet Height | 45mm | |||||
RPM | 1300 | |||||
Brake System | Ancient brake/Disc brake | |||||
Hall Sensors | 3 | |||||
Hall Sensor Phasing | 120° | |||||
Number of motor phases | 3 | |||||
Efficiency | ≥90% | |||||
Rated Out Power | 4500W | |||||
Number of Pole Pairs | 28 | |||||
Cross Section of Phase Wire | 3square | |||||
Waterproof Grade | IP67 | |||||
Color | Black/white etc. | |||||
diameter | 450MM | |||||
Rim width | 100MM | |||||
Open file | 200MM | |||||
Custom order | Can be customized according to customer requirements | |||||
