industry conveyor vegetable dryer vegetable dryer machine dehydrator
- Category: Chemical Machinery & Equipment >>>
- Supplier: Henan,Mayboom,Energy,Saving,Equipment,Co.,Ltd.
Share on:
Product Overview
Description
Product Overview
industry conveyor vegetable dryer vegetable dryer machine dehydrator
1 Vegetable: Asparagus, beans, kidney beans, lentils, eggplant, red pepper, chinese prickly ash, black fungus, tremella, papaya
tablets, bitter melon, radish, cucumber slices, mushrooms, ginger, garlic, etc.
2. Medicinal material: Flos lonicerae, radix scutellariae, zome of rehmannia, mulberries, forsythia, chinese wolfberry, etc;
3. Others: Lily, rose, peony seeds, fennel seeds, etc.
PRODUCT SPECIFICATIONS
Modle | MZ2-6-4 | MZ2-8-4 | MZ2-10-4 | MZ2-12-4 | |||
Layer | 4-6 layers | ||||||
Drying temperature | 0-120 ℃ | ||||||
Drying time | 0.1-5 hours | ||||||
Moisture reduce | 85% ---8% | ||||||
Drying area | 29 m2 | 45 m2 | 57 m2 | 69 m2 | |||
Total power | 14.56kw | 19.25kw | 19.96kw | 26.95kw | |||
Overall dimension | 6000*2200*2300mm | 8000*2200*2300 mm | 10000*2200*2300 mm | 12000*2200*2300 mm | |||
Working principle
Working Principle of Food Dehydrator Vegetable Fruit
The Food Dehydrator Vegetable Fruit utilize the hot air produced by the heat furnace as the drying medium.
Through the hot air distribution unit, the hot air is transported to the mesh belt.
The hot air volume, mesh belt running speed, temperature and humidity can be adjusted by the electric control system, to ensure the continuous and automatic operation.
The Food Dehydrator Vegetable Fruit not only according to heat to dry, but also according to strong air, the air volume can reach 40000 cube meters per hour.
The Food Dehydrator Vegetable Fruit utilize the hot air produced by the heat furnace as the drying medium.
Through the hot air distribution unit, the hot air is transported to the mesh belt.
The hot air volume, mesh belt running speed, temperature and humidity can be adjusted by the electric control system, to ensure the continuous and automatic operation.
The Food Dehydrator Vegetable Fruit not only according to heat to dry, but also according to strong air, the air volume can reach 40000 cube meters per hour.
Advantage
1 Fully automatic drying process , temperature and humidity control .
2 Large capacity , can process 1t -20 t per day .
3 Adopt heat exchange principle , keep material clean .
4 Low temperature and large air volume , gurantee the dried products good color and taste .
CUSTOMER VISIT
Company Profile
Henan Mayboom Energy Saving Eequipment Co. LTD was established in 2011. It is a technical enterprise integrating R & D, manufacturing, sales and after-sales of mechanical equipment.
Product quality is the first priority. The company has set up a special technical research and development department. So far, the company's products have passed more than 30 national patents, and have passed many quality system certification such as ISO, CE, etc.
Based on innovation, efficiency, unity, pragmatism, high quality, gratitude and dedication, the company creates a new enterprise brand, Mayboom, which is people-oriented and quality-oriented.
Product quality is the first priority. The company has set up a special technical research and development department. So far, the company's products have passed more than 30 national patents, and have passed many quality system certification such as ISO, CE, etc.
Based on innovation, efficiency, unity, pragmatism, high quality, gratitude and dedication, the company creates a new enterprise brand, Mayboom, which is people-oriented and quality-oriented.
Equipment delivery
customer feedback
FAQ
Question 1: What are your advantages compared with your competitors?
Answer:
With rich industry experience and strict Product Quality Control systems, we provide:
1). Stable and reliable product at reasonable price
2). Good customer service: Fast response to any inquiry or question
3). On-time delivery.
Question 2: Are you manufacturer?
Answer: Yes, we are manufacturer with more than 10 years' experience.
Question 3: What are your Price Terms?
Answer: Price can be based on FOB, CFR, or CIF, etc.
Question 4: What are your Payment Terms?
Answer: Payment shall be made by T/T, L/C, or D/P, etc., it varies considerably according to the region that you are in.
Question 5: What's your Minimum Order Quantity?
Answer: Any order quantity is warmly welcomed.
Question 6: Do you have English Manual for each machinery?
Answer: Yes. The instruction manual,the test report and other Data Sheets related shall be provided by us.
Question 7: Can I print my Logo on the machine?
Answer: Yes, sure.
Question 8: Can you customize the machine for me ?
Answer: Yes, we can customize according to customer's requirements.
Question 9: What shall we do if breakdown occurs?
Answer: Please informed us once the breakdown occurs. During warranty period, if breakdown occurs, we shall respond in time after
receiving the notification of the buyer. We shall handle failure over the telephone/ fax or arrange relevant personnel to the site
according to the buyer’s requirements.
Question 10: What are your modes of transportation?
Answer: Courier service, Air transport, Sea Transport.
Question 11: Which ports do you usually ship at?
Answer: We can load container at: Qingdao, Shanghai, Ningbo, Tianjin, Guangzhou etc.
Answer:
With rich industry experience and strict Product Quality Control systems, we provide:
1). Stable and reliable product at reasonable price
2). Good customer service: Fast response to any inquiry or question
3). On-time delivery.
Question 2: Are you manufacturer?
Answer: Yes, we are manufacturer with more than 10 years' experience.
Question 3: What are your Price Terms?
Answer: Price can be based on FOB, CFR, or CIF, etc.
Question 4: What are your Payment Terms?
Answer: Payment shall be made by T/T, L/C, or D/P, etc., it varies considerably according to the region that you are in.
Question 5: What's your Minimum Order Quantity?
Answer: Any order quantity is warmly welcomed.
Question 6: Do you have English Manual for each machinery?
Answer: Yes. The instruction manual,the test report and other Data Sheets related shall be provided by us.
Question 7: Can I print my Logo on the machine?
Answer: Yes, sure.
Question 8: Can you customize the machine for me ?
Answer: Yes, we can customize according to customer's requirements.
Question 9: What shall we do if breakdown occurs?
Answer: Please informed us once the breakdown occurs. During warranty period, if breakdown occurs, we shall respond in time after
receiving the notification of the buyer. We shall handle failure over the telephone/ fax or arrange relevant personnel to the site
according to the buyer’s requirements.
Question 10: What are your modes of transportation?
Answer: Courier service, Air transport, Sea Transport.
Question 11: Which ports do you usually ship at?
Answer: We can load container at: Qingdao, Shanghai, Ningbo, Tianjin, Guangzhou etc.
