Yunda Super Pressure Screen OCC Corrugated Cardboard Fluting Paper Life Paper Coarse for Paper Making Machine Mill


Product Description


Super Screen：
As demanded by papermakers in China and combining years' design and manufacturing experienc, Yunda designed this machine, a new generation pressure screen, by applying most advanced 3D modeling and fluid analysis.


Advantages
* Designed on basis of hydrodynamics theory, lower motor power, more energy saving.
* Optimized rotor and screen basket design makes fiber sufficiently fluidized thus higher screening efficiency.
* Module design, stable and reliable structure, saving labor and time for installation and maintenance.
* Equipped with automatic oiling device and mechanical sealing water flow detection device, DCS interface reserved (detection of temperature rise and vibration of bearing), high degree of automation.


Specification




Model
SS10
SS20
SS30
SS35
SS40
SS45
SS50
SS55
SS60
Inlet Dia.（mm）
150
200
250
300
300
400
400
400
400
Accept Dia.（mm）
150
200
250
300
300
400
400
400
400
Heavy Dia.（mm）
80
100
100
125
125
150
150
200
200
Light Reject Dia.(mm)
80
100
100
125
125
250
250
250
250
Dilution Dia(mm)
40
50
50
65
65
65
65
80
80
Nomonal Area(㎡)
0.38
0.62
1.07
1.51
1.80
2.36
2.8
3.39
3.96
Capacity(T/D)
40-120
80-220
120-330
180-450
210-560
270-620
330-870
390-930
450-1100
Max.Motor(KW)
11-22
15-37
37-45
37-55
42-75
45-90
55-110
75-132
90-160


Company Profile




Established in 1981, Zhengzhou YunDa Paper Machinery Co., Ltd. is specialized in the production of pulp making equipment and is the largest complete waste paper pulp making equipment manufacturer in the middle of China. Our company is located in Xuedian Industrial Zone of Xinzheng City, near Zhengzhou International Airport.
Our company covers an area of nearly 66,667 square meters and has more than 300 staff members. Integrating research, design, manufacture and sale, we supply energy-saving pulp-making equipment to the global markets, including Waste Paper Wrap Dry Separating & Screening Systems, various Chain Conveyors, D-Hydrapulpers and waste paper breaking equipment, High-Consistency and Mid-Consistency Cleaners, various inflow and outflow screens, Deinking and Flotation Machines, Refiners, Thickeners, Agitators, various pumps, etc
If you are interested in our products, please feel free to contact us for more information.


The Pulping Equipment
Yunda Paper Machinery Co., Ltd. is China's most competitive manufacturer of complete sets of waste paper treatment, production of stock preparation and approach system equipment., We have all the pulping equipment you need, and we can also customize the colors and labels of your products.


Packing & Delivery


After-Sale Guarantee
We can provide you with a full range of after-sales Field installation, commissioning and training.

Welcome to Visit Our Factory






Exhibition Show
We have many international exhibitions every year, and we will also invite our customers to participate in on-site exchanges.
If there are problems with our products, we are happy to go abroad at any time to communicate with you.


Proven Patents
Yunda has more than 30 patented technologies and has won wide recognition from Chinese and foreign customers!
