Product Overview

Description







JDM11 & JDMS series electronic accumulative counter, adopts low power integrated cirucit, high bright LED display with clear appearance; It has power off memory without machine damage, durable enough. It is widely used to production counting, flow counting, rotation counting, length counting, times counting and such occasions.




Type
Count range
Count input
Count frequency
Reset mode
LED
JDM11-5H
99999
No voltageinput
leave factory set frequency: 10 times per second.(Else frequency can be made to order，Maximum count frequency: contact input: 15 times per second.  pulse input: over 1000 times per second.
Manual reset， if need external reset or not, please mark when do order
0.32" High and bright degree
JDM11-5HV
99999
voltage input



JDM11-6H0
999999
No voltageinput



JDM11-6H0V
999999
voltage input



JDM11-6H1
999999
No voltageinput



JDM11-6H1V
999999
voltage input



JDM11-6H2
999999
No voltageinput



JDM11-6H2V
999999
voltage input



JDM11-6H3
999999
No voltageinput



JDM11-6H3V
999999
voltage input



JDM11-8H
99999999
No voltageinput

External reset

JDM11-8HV
99999999
voltage input



JDM11-6HD
999999
voltage、no voltage input
5、50、500 times/sec
Manual reset、electronic signal reset
0.56"
JDMS-80D
999999



0.8"


Rated voltage
AC 110 240V, AC24V,50/60HZ DC24V, 85%~110%  rated voltage
Environment temperature
-10~+45℃
Count mode
add count
Count inout
Voltage inpput: Voltage count by the contact signal or non-contact signal.(Such as photoelectric switch and proximity switch)
No voltage input type:Contact input and no voltage solid input, integrated open-circuit NPN crystal tube.
Output power signal
DC 12V 60mA
Power comsumption
JDM11-5H/JDM11-6H:240V 50HZ 1W 8H:240V 50HZ 2W 6HD 80D 240V 50HZ 3W
Power off memory
About 10 years(25℃)
