Product Overview

Description







1. Takes humanism and intelligent type as design idea, the complete function can meet various kinds of occasions' application.
2. Touch switch set; set value and counting value are separately displayed by LED, visual and convenient.
3. It has advanced length counting function that takes pulse as modulus and S et correspond counting value.
4. It has the functions of automatic repeat counting, counting alarm in advance and adjustable attraction delay time .
5. Multi-shifts counting frequencies are for choice.(Contact and impulse input counting) .




Item\\Type
JDM11-4S
JDM11-6S
JDM72-4S
JDM72-5S
JDM72-6S
Display count
Two groups of 4 bit LED
6 bit LED
Two groups of 4 bit LED
Two groups of 5 bit LED
Two groups of 6 bit LED
Count range
1-9999
1-999999
1-9999
1-99999
1-999999
Coefficient set up range
0.001-9.999m
0.00001-9.99999m
0.001-9.999m
0.0001-9.9999m
0.00001-9.99999m
Output delay range
0.01-99.99s
0.01-9999.99s
0.01-99.99s
0.01-999.99s
0.01-9999.99s
Rated voltage
AC 110~240V、AC24V,50/60HZ/DC24V, 85-110% Rated voltage
Count mode
Add count(A), Reversible count(B、C、D,3 kinds methods
Count input
Without voltage input(the point of contact tube switch); voltage input H: 4.5~30V, L: 0 ~2V
Count frequency
5、30、200、1000、3000Times/second can be choose
Output type
F、N、R、C、K1、K2、P、Q、A、D、H、L
Control output
2 sets of normally-open contacts
2 sets of contacts AL1, AL2 distinguishes output
Output contact capacity
AC240V 3A resistive load (COSφ=1)
Reset mode
panel 、connection terminal、auto
Output power
DC12V±10% 60mA
Consume electricity
240V 50HZ≤5VA DC24V≤3.5W
Power off memory
Over 10 years (25℃)








Tenglong Electronics Meter Co., Ltd
We are a technology company who specializes in designing manufacturing and severing together. Having gained national patents more than 10 items. The products widely used in industry automation instruments and equipment field, include length measuring, counting, timing , current and voltage , temperature, lubricating time controller, LED tower light and LED alarm light.
