String Inverter Italy Solar Inverter Residential Whole Solar Energy System single Phase Hybrid Inverter
- Category: Solar Energy Products >>>
- Supplier: Beijing,Zhongke,Ruihe,Intelligent,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Technical Datasheet
Model | RV3000H-S2 | RV3680H-S2 | RV4000H-S2 | RV5000H-S2 | RV6000H-S2 | |||||
Battery Input Data | ||||||||||
Nominal battery voltage | 48 V/51.2V | |||||||||
Battery voltage range | 40 V to 60 V | |||||||||
Max. charging / discharging power | 5000 W / 5000 W | |||||||||
Max. charging current / Max. discharging current | 100 A / 100A | |||||||||
Battery type | LiFePO4 | |||||||||
PV Input | ||||||||||
Max. PV array power | 5500 Wp STC | 6180 Wp STC | 6500 Wp STC | 7500 Wp STC | 9000 Wp STC | |||||
Max. input voltage | 550 V | |||||||||
Max. input current per MPP tracker | 16 A | |||||||||
Max. short-circuit current per MPP tracker | 20 A | |||||||||
General data | ||||||||||
Dimensions (W / H / D) | 483 / 455 / 193.5 mm | |||||||||
Device weight | 25.1kg | |||||||||
Operating temperature range | -25 °C - 60 °C | |||||||||
Noise emissions (typical) | 30 dB(A) | |||||||||
Standby consumption | < 10 W | |||||||||
Cooling concept | Natural convection | |||||||||
Degree of protection (as per IEC 60529) | IP66 | |||||||||
Max. operating altitude | 4000m (>3000m power derating) | |||||||||
Features | ||||||||||
User interface | LED & App | |||||||||
Communication with BMS | RS485 / CAN | |||||||||
Communication with meter | RS485 | |||||||||
Communication with portal | WIFI stick | |||||||||
Model | RV3000H-S2 | RV3680H-S2 | RV4000H-S2 | RV5000H-S2 | RV6000H-S2 | |||||
Battery Input Data | ||||||||||
Nominal battery voltage | 48 V/51.2V | |||||||||
Battery voltage range | 40 V to 60 V | |||||||||
Max. charging / discharging power | 5000 W / 5000 W | |||||||||
Max. charging current / Max. discharging current | 100 A / 100A | |||||||||
Battery type | LiFePO4 | |||||||||
PV Input | ||||||||||
Max. PV array power | 5500 Wp STC | 6180 Wp STC | 6500 Wp STC | 7500 Wp STC | 9000 Wp STC | |||||
Max. input voltage | 550 V | |||||||||
Max. input current per MPP tracker | 16 A | |||||||||
Max. short-circuit current per MPP tracker | 20 A | |||||||||
General data | ||||||||||
Dimensions (W / H / D) | 483 / 455 / 193.5 mm | |||||||||
Device weight | 25.1kg | |||||||||
Operating temperature range | -25 °C - 60 °C | |||||||||
Noise emissions (typical) | 30 dB(A) | |||||||||
Standby consumption | < 10 W | |||||||||
Cooling concept | Natural convection | |||||||||
Degree of protection (as per IEC 60529) | IP66 | |||||||||
Max. operating altitude | 4000m (>3000m power derating) | |||||||||
Features | ||||||||||
User interface | LED & App | |||||||||
Communication with BMS | RS485 / CAN | |||||||||
Communication with meter | RS485 | |||||||||
Communication with portal | WIFI stick | |||||||||
Packing & Delivery
Why RahVolt?
Our employees are not just engineers, sales professionals or production experts. They are revolutionaries, giving their best to spread and implement the idea of energy for everybody. That's why they are our biggest assets and that's why they are awarded with more than just a satisfying career, but also with the knowledge that they are contributing to an important change of the world.
The solar revolution is going global, so it's important that it is led by an internationally experienced management team. Their expertise in running big multinational companies allows them to draw out the synergy of cooperation between different departments, from Research & Development and Operations to Sales and Marketing.
It is not a coincidence that RahVolt stands for everybody's right to access to solar power. Giving power to everybody is something our management believes in strongly. We are a company that not only respects every individual in our ranks, but also encourages the culture of free exchange of ideas and initiatives.
The solar revolution is going global, so it's important that it is led by an internationally experienced management team. Their expertise in running big multinational companies allows them to draw out the synergy of cooperation between different departments, from Research & Development and Operations to Sales and Marketing.
It is not a coincidence that RahVolt stands for everybody's right to access to solar power. Giving power to everybody is something our management believes in strongly. We are a company that not only respects every individual in our ranks, but also encourages the culture of free exchange of ideas and initiatives.
FAQ
1. who are we?
We are based in Beijing, China, start from 2022,sell to Mid East(17.00%),South America(14.00%),Southeast Asia(13.00%),Eastern Europe(11.00%),Africa(10.00%),Eastern Asia(8.00%),Western Europe(8.00%),Southern Europe(6.00%),Central America(5.00%),South Asia(3.00%),Domestic Market(3.00%),Northern Europe(2.00%). There are total about 1000+ people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
solar inverter,solar battery,lithium battery,solar system,hybrid energy system
4. why should you buy from us not from other suppliers?
15 years industry experience
more than 50 R&D people
professional sales team
10 years warranty
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,FCA,DDP,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian.
We are based in Beijing, China, start from 2022,sell to Mid East(17.00%),South America(14.00%),Southeast Asia(13.00%),Eastern Europe(11.00%),Africa(10.00%),Eastern Asia(8.00%),Western Europe(8.00%),Southern Europe(6.00%),Central America(5.00%),South Asia(3.00%),Domestic Market(3.00%),Northern Europe(2.00%). There are total about 1000+ people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
solar inverter,solar battery,lithium battery,solar system,hybrid energy system
4. why should you buy from us not from other suppliers?
15 years industry experience
more than 50 R&D people
professional sales team
10 years warranty
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,FCA,DDP,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian.
