Big Promotion in EU Automatic Pick & Place SMT550 pcb Production Line with 6 Cameras Automatic Assembly Line
- Category: >>>
- Supplier: Wenzhou Yingxing Import&Export Co. Ltd.
Share on (1601206198515):
Product Overview
Description
Product Description
Introduction
The machine SMT550 with the ball screw and servo motor which is more stable and more accurate than the step motor.
Feature
1.Panasonic servo motor.
2.Straight guide rail.
3.Screw Guide.
4.4 Heads+50 feeders+6 cameras.
Part list
1.Pick and place machine:1Set 2.IC fixed support:4Set(four M5*8,four M5*16)
3.JUKI nozzle:12Pcs (502*2，503*3，504*4，505*2，506*1)
4.Calibration suction nozzle:4Pcs
5.Power wire:1Pcs
6.Fixed foot:4Pcs(Diameter 20mm)
7.The keyboard and mouse:1Set
8.Nozzle calibration inkpad:1Box
9.lubricant:1Pcs
10.Chassis key:1Pcs
11.PC:1Set
12.17 inch liquid crystal display:1Set
The SMT550 software was developed by ourselves. The software is available in English. And our software will be updated, as soon as there is an update, the salesman will send new software to your mailbox.
The SMT550 machine has one year warranty, lifetime maintenance. We have a professional after-sales team. As long as there is a problem with the machine within one year after purchase, we will repair it for free. If there is a need to replace the accessories, we will send them to your hands for free.(Generally we use TNT/DHL. 3-5 business days to your hands).
The machine SMT550 with the ball screw and servo motor which is more stable and more accurate than the step motor.
Feature
1.Panasonic servo motor.
2.Straight guide rail.
3.Screw Guide.
4.4 Heads+50 feeders+6 cameras.
Part list
1.Pick and place machine:1Set 2.IC fixed support:4Set(four M5*8,four M5*16)
3.JUKI nozzle:12Pcs (502*2，503*3，504*4，505*2，506*1)
4.Calibration suction nozzle:4Pcs
5.Power wire:1Pcs
6.Fixed foot:4Pcs(Diameter 20mm)
7.The keyboard and mouse:1Set
8.Nozzle calibration inkpad:1Box
9.lubricant:1Pcs
10.Chassis key:1Pcs
11.PC:1Set
12.17 inch liquid crystal display:1Set
The SMT550 software was developed by ourselves. The software is available in English. And our software will be updated, as soon as there is an update, the salesman will send new software to your mailbox.
The SMT550 machine has one year warranty, lifetime maintenance. We have a professional after-sales team. As long as there is a problem with the machine within one year after purchase, we will repair it for free. If there is a need to replace the accessories, we will send them to your hands for free.(Generally we use TNT/DHL. 3-5 business days to your hands).
Maximum circuit board area | 400*200 mm |
Number of mounting heads | 4 |
Maximum movement range of Z axis | 20 mm |
Maximum mounting rate | 9,500 PCS/hour |
Average mounting rate | 8,000 PCS/hour |
Positioning accuracy | 0.01 mm |
Buffering range of suction nozzle | 4.5 mm |
Power supply | 220V/110V, 50 Hz |
Compressed air | 0.6-0.7 Mpa |
Average power | 400 W |
Recognition Mode | Four Heads Synchronized Recognition |
Number of cameras | a Mark camera, four high-speed cameras, a high-definition camera |
Product weight | 210KG |
PCB access mode | automatic Left-in and right-out access, supporting left-right device connection function |
Quantity of trays | Up to 48 non-feeder feeding components are supported, each of which can specify its coordinates within the mounting range |
Complex speed to mount resistance and Chip | 6000/h |
Mounting accuracy range | 0201-40*40mm,Pin spacing 0.3mm |
Chip(Matching which support electric feeder can mount the 0402,0201) | |
Quantity of feeders | 50 PCS |
Service motor | Panasonic servo motor |
Guide rail | Taiwan TBI Linear Guide rail |
Driving mode | Taiwan TBI ball screw |
Nozzle Vacuum Source | Japan CKD High Speed On-off Vacuum Generator with Vacuum Damage |
Minimum air capacity of pump | 80-120 L/min, volume more than 60 L |
Gas quality requirements | oil-water separation device, dust filter device, air pressure stabilization device |
Dimension | 900×1140×900mm |
