Chip Y Capacitor 102/400V CKD Material BOM kit for 20W Type C PD GaN Charger
- Category: >>>
- Supplier: shenzhen CXW technology CO. LTD.
Share on (1601206747994):
Product Overview
Description
Product name：20W PD charger CKD Kits
Power： 20W，PD fast charging.
Input：100~240Vac，50/60Hz. 0.4A.Output:
TYPE-C:5V3A,9V2.2A,12V1.67A@20W
PPS:3.3-11V.
Charging protocol：
Support PD2.0/3.0,/QC2.0/3.0/PPS/AFC/SCP and other protocols.
Protection function:
short circuit/over power/over temperature/over voltage protection, etc.
PCB Size： 36x36x1.0 mm
Input：100~240Vac，50/60Hz. 0.4A.Output:
TYPE-C:5V3A,9V2.2A,12V1.67A@20W
PPS:3.3-11V.
Charging protocol：
Support PD2.0/3.0,/QC2.0/3.0/PPS/AFC/SCP and other protocols.
Protection function:
short circuit/over power/over temperature/over voltage protection, etc.
PCB Size： 36x36x1.0 mm
Chip Selection of PD Charger
SSR Series— Main Control
Model | Standby Power | Working Model | Control Way | Recommend Power | Package |
CX7170Q | ＜75mW | PWM/QR | External drive GaN 200KHz | 30W | SOT23-6 |
CX75GD080S | ＜75mW | PWM/QR | Integrated GaN | 20W | SOP-8L |
CX75GD025E | ＜75mW | PWM/QR | Integrated GaN | 45W | ESOP-10W |
CX75GD015E | ＜75mW | PWM/QR | Integrated GaN | 65W | ESOP-10W |
SR Series—Synchronization
Model | Frequency | Working Model | Withstand Voltage (Built-in MOS) | Rds(on) | Package |
CX7538BS | ＜200kHz | CCM/DCM/QR | 60V | 12mΩ | SOP-8L |
CX7601 | ＜150KHz | CCM/DCM/QR（External drive MOS） | Controller withstand voltage 150V | NA | SOT23-6 |
