PCB Assembly circuit board Gerber file BOM List pcba manufacturer OEM SMT
- Category: >>>
- Supplier: Shenzhen Wanfeng Technology Co. Ltd.
Share on (1601208345003):
Product Overview
Description
POE is an OEM manufacturer that focus on PCB & PCBA manufacturing over 20 years. We have the capability to manufacture PCB ranging from basic single sided boards up to 40 layer multilayer PCB, and provide one-stop turnkey services, including PCB layout, manufacture, assembly, components source, function testing services, and so on. We established in 1996 and always provide high quality, technically advanced products within the customer's timescales so that we can provide the best electronic services for you. This commitment, combined with the wealth of experience and expertise we have built up over the years, means we can offer a total solution to our customers PCB requirements - from front end engineering through to in time deliveries.
Specification | ||
Item | Value | |
Model Number | PCB | |
Type | Consumer Electronics PCBA | |
Place of Origin | China | |
Brand Name | PCB Board | |
Supplier Type | Custom | |
Surface Finishing | Immersion Gold | |
Application | Electronics Device | |
Product Name | Electronic Components Assembly PCB | |
Service | 24 Hours Technical Service | |
Certificate | ISO9001/ ISO13485/ ISO14001/ CE/ ROHS/ UL/REACH | |
Solder Mask | Green, Red, Blue, Black, Yellow, Grew | |
Copper Thickness | 1-6 OZ | |
Board Thickness | 1.6mm | |
Min. Line Width | 0.1mm/4mil | |
Min. Hole Size | 0.2mm | |
FAQ
Q: What is needed for PCB/PCBA quotation?
A: For Bare PCB project, please provide Quantity, Gerber file and specification like material, surface finish treatment, copper thickness, board thickness, soldermask color and silkscreen color and other special specs.
For PCBA project, please provide above information as well, and BOM list, pick and place file. If you need turnkey service include programming and functional testing etc, kindly contact us for more details.
Q: Are my files safe?
A: Your files are held in complete safety and security. We protect the intellectual property for our customers in the whole process.
All documents from customers are never shared with any third parties. We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential level.
Q: What’s your minimum of quantity (MOQ)?
A: There is no MOQ in POE (PCBA shenzhen). We are able to handle small as well as large volume production with flexibility.
Q: How to calculate the shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
Q: What other service do you have?
A: We mainly focus on PCB+ Assembly+ Components sourcing service. Additionally, we can also provide programming, testing, cables, enclosure assembly service.
Q: Can we inspect quality during production?
A: Yes, we are open and transparent on each production process. We Welcome you visit our factory to inspect our production process.
Q: What is your testing policy and how you control the quality?
A: Regarding to PCB samples, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by Electrical fixture which is faster. As to PCBA production, there are automated optical inspection (AOI) for each batch, X-ray inspection for BGA parts, first article inspection (FAI) before mass production.
For PCBA project, please provide above information as well, and BOM list, pick and place file. If you need turnkey service include programming and functional testing etc, kindly contact us for more details.
Q: Are my files safe?
A: Your files are held in complete safety and security. We protect the intellectual property for our customers in the whole process.
All documents from customers are never shared with any third parties. We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential level.
Q: What’s your minimum of quantity (MOQ)?
A: There is no MOQ in POE (PCBA shenzhen). We are able to handle small as well as large volume production with flexibility.
Q: How to calculate the shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
Q: What other service do you have?
A: We mainly focus on PCB+ Assembly+ Components sourcing service. Additionally, we can also provide programming, testing, cables, enclosure assembly service.
Q: Can we inspect quality during production?
A: Yes, we are open and transparent on each production process. We Welcome you visit our factory to inspect our production process.
Q: What is your testing policy and how you control the quality?
A: Regarding to PCB samples, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by Electrical fixture which is faster. As to PCBA production, there are automated optical inspection (AOI) for each batch, X-ray inspection for BGA parts, first article inspection (FAI) before mass production.
