Точное автоматическое постоянное натяжение, ПЛК контроль, металлическая машина для продольной резки пряжи (1867864716)

Share on:


Price:8 700,00 $ - 9 000,00 $
Price in USD:Details

Quantity:


Product Overview

Description


Metallic Yarn Slitting Machine






Product Description


Professional Manufacturer


1. Safety first, quality first .


2. Strict and advanced workshop management system .


3. The human production, people-oriented .


4. High quality products to provide high quality environment




Specifications


The machine applies to slit cellophane, PET, OPP, CPP, PE, PS, PVC and computer security labels, electronic computers, optical materials, film roll, foil roll, all kinds of paper rolls, film and printing of various materials, etc.
Features:
1, Unwinding unit: it adopt air shaft for loading.(optional device: non-axial Air pressure and get way with Air Chuck, who is caught taking raw materials fast, easy loading, single-person operation). EPC (Edge position control) uses imported LPC corrective device, it can achieve guide function by material edge and printed mark.( E+L Germany brand as optional)
Unwinding tension adopts magnetic powder brake through PLC to achieve a constant tension.(optional device: using independent vector variable frequency electrical parameters of the original pre-computing to achieve a constant tension).
2, Slitting Unit: This machine equipped with two kinds of slitting method: Flat knife slit and circular knife slit. (Circle knife is optional device).


3, Rewinding Unit: It uses of one motor connect with two magnetic powder clutch winding way(optional device: two vector motor), rewinding shaft is air shaft (optional device: pneumatic fall slip-shaft that ‘s pressure in center by pneumatic) ; With automatic tension compensation system, so that rewinding tension is steady ,don’t adjust tension in accordance with the speed and diameter increases.
4, winding sticks pressure unit : The machine is equipped with two sets of pneumatic pressure automatic lifting sticks, tension automatic control by computer.


5, waste edge processing section: This model is equipped with a vacuum-type waste edge exclusion system, use the strong force adsorb the waste edge out away


6, Electrostatic elimination Unit(optional device): The machine equipped a group of static brush apart on up and down rewinding shaft , which can effectively eliminate the static between slitting and rewinding .


7, Finished Produce unloading Unit :
It is a discharge rack can provide a larger diameter of the finished product is simple and efficient to operate and save time for the next feed.
8, PLC control system: Adopt imported PLC to achieve accurate and stable control, true color touch screen display to enable simple and beautiful images. Interactive parameter setting the environment, eliminating the complicated configuration can start the job: The user pre-start only need to input the material thickness, width, density, diameter and speed parameters, the next will be done automatically by a computer calculation to complete.





Main technical parameter:
























































Jumbo roll width



1000mm



1300mm



Diameter of roll



1000mm



1000mm



Diameter of rewinding



600mm



600mm



Inner dia.of paper core



3''or 76mm(optional:  6''or 152mm)



3''or 76mm(optional:  6'' or 152mm)



Slitting speed



10-400m/min



10-400 m/min



Tolerance of EPC



≤0.1mm



≤0.1mm



Min.width of produce



50mm



50mm



Total power



20KW



20KW



Weight



3800Kg



4500kg



overall dimension (L X W X H)



2400mm×420mm×1900mm



2700mm×4500mm×1900mm






Metallic Yarn Slitting Machine






Certifications










stretch film CE_CE printing machine_CE printing machine_







Packaging & Shipping


1. Machine will be tested before shipping


2.Packing : If shipped FCL, stretch Film wrapping with anti rust treatment; if shipped LCL, stretch film wrapping with anti rust treatment, wooden case package.




Metallic Yarn Slitting Machine



FAQ


Metallic Yarn Slitting Machine





Our Services


1. Machine customized is available


2. 24 hours online service


3. After sales service: Technician is available to overseas for machine installation and training.


4. All machines are with 13 months guarantee time, and with whole life technical support


5. Within warranty time, free parts replacements and maintenance service are available
