High temperature 2200.C energy saving frit furnace for metal melting (60779925160)

Share on:


Price:RUB 37,942.30 - RUB 227,653.80
Price in USD:Details

Quantity:


Product Overview

Description

High temperature 2200.C energy saving frit furnace for metal melting

Product Show


0-97.jpg 0-99.jpg
Product Description

product description

           Main technical parameter
Project Index value
Rated voltage 380V
Heating rate ≤1-40 ℃ / min (user-friendly adjustable)
Temperature control accuracy ± 1 ℃
Temperature control method PID regulation, microcomputer control, programmable temperature curve, without caretaker (automatic heating, insulation, cooling)
Double circuit protection Over-temperature, overpressure, superfluidity, broken even, power failure and so on
Thermocouple type B type / S type
Heating element Imported high-quality silicon molybdenum rods / high-quality silicon carbon rod / high-quality resistance wire
Furnace material Made of imported composite alumina fiber, good insulation performance, high temperature resistance and thermal shock resistance.

Lifting structure Automatic screw screw up and down, smooth without vibration
Loading and material flow method Top loading, bottom flow
Shell surface temperature ≤35 ℃
Temperature category 800 ° C 1000 ° C 1200 ° C 1400 ° C 1600 ° C 1700 ° C 1800 ° C
            Application

    Equipment widely used in universities, research institutes, industrial and mining enterprises such as powder, military, electronics, metallurgy, medicine, ceramics, glass, machinery, new material development, special materials, refractory materials, building materials, chemicals, metal sintering and metal heat treatment Experiment and production.

            Technical characteristics

    1.LYL-18RK series lifting frit furnace introduced advanced technology, independent research and development of energy-saving, environmental protection, new electric furnace, with advanced and reasonable structure, nice appearance, high-quality cold-rolled steel shell, the advanced CNC machining, luxury, beautiful Of the two-color imported epoxy powder electrostatic spray process, processed, high temperature, corrosion-resistant, the use of high-quality heating elements, double furnace shell with air-cooled system, can quickly cool the furnace temperature equilibrium, the furnace Surface temperature is low, fast heating and lowering speed, energy saving and so on. Furnace imported composite alumina fiber material built by the numerical control process, thermal shock resistance, good corrosion resistance, no collapse, no crystallization, no residue, no pollution, long service life. The control system adopts microcomputer artificial intelligence adjustment technology, with PID regulation, automatic control, self-tuning function, multi-section programming, and can be programmed a variety of heating, insulation, cooling program, high temperature control accuracy; integrated module SCR control, phase shift Trigger, protect the system: the use of independent over-temperature protection, over-voltage, ultra-current, leakage, short circuit protection. High degree of automation, the indicators reached the advanced level.

    2.Honors: ISO9001: 2008, AAA business, CE certification

            Furnace size
 Crucible volume (L)  Voltage (V) Power (kw)   Temperature control accuracy
0.9  220 4  ± 1 ℃
1.6  380 10  ± 1 ℃
3 380 12  ± 1 ℃
5 380 15  ± 1 ℃
 15  380 18  ± 1 ℃
 30  380 25  ± 1 ℃

Crucible volume can be customized according to customer requirements!


List of selectable accessories

Separate control cabinet

Touch screen instrument

Remote auxiliary module

Observation window

Air-bleed hole and chimneys

Heat fan

Crucible

Door plugging

Hearth plate

Alundum tube

Quartz tube

Vacuum pump

Production Flow

production flow

Main Products

main products

Company Information

company info

Luoyang Liyu Kiln Co., Ltd. is a large electric furnace manufacturing base integrating R&D, production, sales, and service. Base on professional technology and manufacturing team with over 20 years of manufacturing experience, design and manufacture of various sizes and models, a variety of high-precision electric furnace and kiln for customer according to the user requirements.

Our products mainly include high temperature muffle furnace, frit furnace, vacuum atmosphere furnace, tube furnace, box furnace and vertical furnace, etc. These products are widely used in universities, research institutes, industrial and mining enterprises for experiment and production of powder, military, electronics, metallurgy, medicine, ceramics, glass, machinery, new material development, special materials, refractory materials, building materials, chemicals, metal sintering and metal heat treatment.

We continually develop the new products, and have developed a series of energy-saving JNL furnace, furnace products with more excellent conditions of fast heating, high energy, high precision, high stability, good thermal insulation performance, full microcomputer control, programmable automatic warming, cooling, heat preservation, furnace surface temperature near room temperature etc.

In recent years, Liyu has passed ISO 9001:2008 quality management system certification in 2015, and in product safety, we passed the CE certification.

Sincerely welcome new and old customers to visit and negotiate.
