Q35Y 20 90Ton Double Cylinder Hydraulic Ironworker Steel Angle Bar Cutting Machine
- Category: Hydraulic Ironworker >>>
- Supplier: Nantong Super Machinery Co. Ltd.
Share on (60558203993):
Product Overview
Description
Product Description
Hydraulic Iron Worker Product Application
They adopt hydraulic driving system and they are the latest iron workers in our country, various metal plate, square bar, Round bar, angle, channel and joist can be cut, punched and notched on the machine. It is also equipped with a stop device for cutting.
1)\t2 separate hydraulic piston and foot pedal to allow 2 operator to work at the same time2)\tMore productivity with adjustable piston stroke distance
3)\tCentral lubrication system
4)\tElectrical back gauge
5)\tWorking light
6)\tFive individual workstation on the machine:
a)\tØ26 mm punch and die and standard punching tools
b)\tSteel solid round and square bar cutting blade set
c)\tAngle cutting blade set
d)\tSheet metal cutting shear
e)\tU-Notching blade set
SPECIFICATIONS FOR HYDRAULIC IRON WORKER | ||||||||||
Specification | Model | Q35Y-12 | Q35Y-15 | Q35Y-16 | Q35Y-20 | |||||
Process Capacity | 40T | 55T | 60T | 90T | ||||||
Punching | Dia.(punch)*Thickness(mm) | 22*12 | 24*15 | 25*16 | 30*20 | |||||
Ram Stroke(mm) | 60 | 60 | 80 | 80 | ||||||
No. of stroke(times/min) | 8 | 8 | 8 | 8 | ||||||
Cutting | Max.thickness of plate (mm) | 12*250 | 15*300 | 16*250 | 20*330 | |||||
Max. width of plate (mm) | / | / | 8*400 | 10*480 | ||||||
Angle Shearing | 900 shearing (mm) | 100*10 | 120*12 | 125*12 | 140*12 | |||||
450 shearing (mm) | 70*6 | 60*6 | 50*5 | 50*5 | ||||||
Notching | Thickness (mm) | 12 | 15 | 16 | 20 | |||||
Width (mm) | 22 | 24 | 25 | 30 | ||||||
Depth (mm) | 200 | 200 | 300 | 350 | ||||||
SPECIFICATIONS FOR HYDRAULIC IRON WORKER | ||||||||
Specification | Model | Q35Y-25 | Q35Y-30 | Q35Y-40 | ||||
Process Capacity | 110T | 140T | 200T | |||||
Punching | Dia.(punch)*Thickness(mm) | 35*25 | 38*26 | 41*35 | ||||
Ram Stroke(mm) | 80 | 80 | 100 | |||||
No. of stroke(times/min) | 6 | 6 | 8~25 | |||||
Max.thickness of plate (mm) | 25*330 | 30*355 | 35*400 | |||||
Max. width of plate (mm) | 16*600 | 20*600 | 25*700 | |||||
900 shearing (mm) | 160*14 | 180*16 | 200*18 | |||||
450 shearing (mm) | 60*6 | 60*6 | 80*10 | |||||
Notching | Thickness (mm) | 25 | 26 | 35 | ||||
Width (mm) | 35 | 38 | 41 | |||||
Depth (mm) | 400 | 600 | 60 | |||||
Detailed Images
Punching Station
Solid Stock , Flat Bar and Angle Shearing Stations.
Rectangle Notching Station
Mould Tooling and Samples.
