Промышленные большие потолочные вентиляторы с большой площадкой диаметром 24 фута

Product Overview

Description

Panama air ventilation factory 24 foot diameter Big Ass industrial large ceiling fans



Our HVLS ceiling fan is a new solution of Energy Saving to solve ventilation,
cooling and dehumidification in large indoor place.


It is High Air Volume and Low Rotating Speed


From the center along the blades, blade's width and thickness gradually are narrowed and thin, in accordance with the modern aerodynamical  science, the whole blades drive more and even airflow downward, no empty zone in center area.

The streamline design of the (windward side)  cross-sectional of the blade decreases the airflow resistance.

Spire of the blade tilts up 3 degrees than the root part, conical air flow instead of cylinder one can directly cover a larger area and it makes airflows much more similar to natural intermittent wind.

For our super ceiling fan , The powerful blades with aerodynamic design move much more indoor air,keeping the surface of the goods dry in wet season.




Model	Diameter	Max Speed	Covering Spacing	Air Volume (CFM)	Moter Power	Weight
GFAN25	2500mm (8 FT)	129rpm	200m2	40000	1.1kkw	70kg
GFAN31	3100mm (10FT)	114rpm	350m2	74000	1.1kw	75kw
GFAN33	3700mm (12FT)	95rpm	500m2	102000		85kg
GFAN43	4300mm (14FT)	83rpm	600m2	114000		110kg
GFAN49	4900mm (16FT)	75rpm	900m2	193000	1.5kw	120kg
GFAN61	6100mm (20FT)	67rpm	1200m2	292000		125kg
GFAN73	7300mm (24FT)	53rpm	1500m2	363000		130kg
