Product Overview
Description
Lifting Magnet can handle tones of scrap continuously throughout the day. they can lift steel more quickly and conveniently than any other mechanical device. Suitable for transferring cast ingots, steel balls, metal and steel scraps.
Suitable for cast ingot ,steel ball ,machine chip ,for various kinds of steel scraps ,return scrape ,cropping ,baling scraps and etc in foundry factories and for iron powder in coal washery ,during slag disposal process ,it can remove large size of iron at initial step .Outlet box has two chambers, an extra-thick fender and an anti-twist setting .
Model | Current in cold state ( A) | Power in cold state (KW) | Lifting capacity (kg) | Weight (kg) | Overall dimension (mm) | Control Equipment | Cable reel & Cable Connector | ||||||
Single steel ball | Packed steel ingots | Packed steel scraps | A | B | C | D | E | ||||||
MW5-70L/1 | 15 | 3.3 | 2500 | 380/200 | 120/100 | 490 | 700 | 800 | 160 | 90 | 30 | STML-4E-C | JTA75-15-2 DL-102 |
MW5-80L/1 | 18 | 3.96 | 3000 | 480/250 | 150/130 | 620 | 800 | 800 | 160 | 90 | 30 | STML-4E-C | |
MW5-90L/1 | 26.6 | 5.85 | 4500 | 600/400 | 250/200 | 800 | 900 | 1090 | 200 | 125 | 40 | STQL-7E-C | |
MW5-110L/1 | 35 | 7.7 | 6500 | 1000/800 | 450/400 | 1350 | 1100 | 1140 | 220 | 150 | 45 | STQL-9E-C | JTA100-15-2 DL-102 |
MW5-120L/1 | 45.5 | 10 | 7500 | 1300/1000 | 600/500 | 1700 | 1200 | 1180 | 220 | 150 | 45 | STQL-14E-C | |
MW5-130L/1 | 54 | 11.9 | 8500 | 1400/1100 | 700/600 | 2060 | 1300 | 1240 | 250 | 175 | 50 | STQL-14E-C | |
MW5-150L/1 | 71.2 | 15.6 | 11000 | 1900/1500 | 1100/900 | 2830 | 1500 | 1250 | 350 | 210 | 60 | STQL-19E-C | |
MW5-165L/1 | 75 | 16.5 | 12500 | 2300/1800 | 1300/1100 | 3200 | 1650 | 1590 | 370 | 230 | 75 | STQL-19E-C | |
MW5-180L/1 | 102.4 | 22.5 | 14500 | 2750/2100 | 1600/1350 | 4230 | 1800 | 1490 | 370 | 230 | 75 | STQL-25E-C | JTA200-15-2 DL-202 |
MW5-210L/1 | 129 | 28.4 | 21000 | 3500/2800 | 2200/1850 | 7000 | 2100 | 1860 | 400 | 250 | 80 | STQL-32E-C | |
MW5-240L/1 | 154 | 33.9 | 26000 | 4800/3800 | 2850/2250 | 9000 | 2400 | 2020 | 450 | 280 | 90 | STQL-38E-C | |
Lifting Magnet Lifting Magnet Lifting Magnet Lifting Magnet Lifting Magnet Lifting Magnet Lifting MagnetLifting
Advantages of Our Lifting Magnet
1) Attractive, small size, light weight, lifting capacity, easy and safe operation.
2) Running in a high automatization and intellectualization.
3) Adopt totally sealing structure with good property of moisture-proofing.
4) Simple and convenient installation, operation and maintenance.
5)Majorized design by computer with reasonable structure, light dead-weight, strong attraction force .
Lifting magnet for excavator / Lifting electromagnet for overhead / Lifting magent for gantry crane
