Product Overview

Description


Product Description

Super large air volume, ultra-long air blowing, feel the free wind everywhere

79'' Diameter Brushless DC Motor Waterproof Large Cooling Portable Floor big HVLS Fans
79'' Diameter Brushless DC Motor Waterproof Large Cooling Portable Floor big HVLS Fans ----Airmove Series is a portable large volume fan newly developed by KALEFANS. The fan is high to 2M and can be moved easily indoors and outdoors with 4 wheels added. Meanwhile, the fan adopts PMSM motor to drive the fan blade, which can produce large&continuous air. In hot & stuffy weather, the cooling effect of one Airmove Series fan is comparable to the effect of more than 20 sets small fan. The entire steel frame of the fan is integrated designed, sturdy and durable, so it can be used in most of places with complicated situations.Airmove Series is a kind of fan with high volume and low speed which is widely used indoors&outdoors, not only to ventilate&cool, but also to be a portable wind source to feel the cooling everywhere. Where is required wind, there is a Airmove fan.


Benefits of Kale HVLS fans:

Keeps employees cool and comfortable
Reduces energy consumption and heating costs in the winter
Protects product integrity
Improves general working conditions
Overall ventilation proposal

\t
Technical Data
\t
Model
\t
SHVLS-Y6BAA20
\t
Dimensions(WXHXD)
\t
2190mmX2000mmX748mm
\t
Max Speed
\t
220r/Min
\t
Range of wind speeds
\t
0-24m(7m/s-0.9m/s)
\t
Full load air volume
\t
1068m³/min
\t
Motor Type
\t
PMSM Motor
\t
Full-load Current
\t
1.8A
\t
Sound Level (Max. Speed)
\t
43dBA
\t
Protection Levels
\t
IP55
\t
Weight
\t
213KGS

79'' Diameter Brushless DC Motor Waterproof Large Cooling Portable Floor Fans big HVLS Fans ----Airmove series Main Features


1, Super large air volume: Ultra-long air blowing, the effective distance is more than 18m;
2, Move easily: Designed with 4 wheels, the fan is able to move everywhere easily;
3, Energy saving: With only 0.4KW power, very low energy comsuption;
4, Quiet & Low noise: Low noise with only 43DB level.
5, Stepless Speed Control: PMSM motor driving fan blade, VFD stepless peed control, easy to operate;
6, Waterproof/Dustproof: Protection level is IP55, waterproof in overall. The fan can be used in rainy/humid days and is easy to clean with water;
7, Modularization installation: The fan is modular design, which is suitable for carrying and easy to be installed.

Certifications
Detailed Images

Airmove Wind Speed Explanation


The wind speed in every area is different.The shadow parts show the coolig area of the fan.The darker the shadow is , the faster the speed is.
The air blowing distance is up to 18m, Within the distance of 18m, the speed decreases from 7m/s to 0.9m/s(the longer, the slower)
The data is obtained at the max speed of motor. The motor is stepless speed control, the speed range is 0-220rpm/min.

.

Airmove series Product drawing

Brushless PMSM Motor


Controller

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
\t
Packaging
\t
Size
\t
2250 (L) * 2100(W) * 850 (D)mm
\t
Weight
\t
330KG
\t



Packaging Details
\t
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
\t
Packaging
\t
Size
\t
2250 (L) * 2100(W) * 850 (D)mm
\t
Weight
\t
330KGS
\t



Packaging Details
\t
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
